The following table lists the feature availability for each XIV model.
Table 15. Ruggedized rack features
Feature description
Feature code
Model
281x-114
Model
281x-214
Model
281x-314
Ruggedized rack 0080 0080 0080
See “Preparing for the ruggedized rack” on page 34 for information about
requirement for preparing the installation site before the ruggedized rack option
can be installed.
Rear-door heat exchanger feature
The rear-door heat exchanger (feature code 0082) is an optional water-cooled
device that is mounted on the rear of an IBM XIV Storage System. It cools the air
that is heated and exhausted by devices inside the rack.
A supply hose delivers chilled, conditioned water to the heat exchanger. A return
hose delivers warmed water back to the water pump or chiller (referred to as the
secondary cooling loop). The primary cooling loop supplies the building chilled
water to secondary cooling loops and air conditioning units. The hoses for the
secondary cooling loop are not included with this option.
The rack on which you install the heat exchanger can be on a raised floor or a
non-raised floor.
The rear-door heat exchanger option consists of the following components that are
shown in Figure 5 on page 23.
v Door assembly
v Hinge kit
v Air-purge tool
22 IBM XIV Gen3 281x-11x, 281x-21x, and 281x-314 Planning Guide
