Icare HOME2 - Buttons and Parts

13
6.4 Buttons and parts
WARNING! Removing, covering, or defacing any label or sign on the tonometer voids all
the responsibilities and liabilities of the manufacturer concerning the safety and
effectiveness of the tonometer.
1
2
5
3
4
8
9 1011 12
12
14
13
15
16
67
1. Measure button
2. Navigation buttons
3. Select button
4. Return button
5. Display
6. Battery cover
7. USB-C port and USB cover
8. Wrist strap
9. Forehead support
10. Cheek support
11. Probe
12. Probe base
13. Infrared LED transmitters
14. Infrared LED sensor
15. Probe applicator
16. Screwdriver
