iCarsoft HD V3.0 - Outline of HD V3.0

Heavy Duty & OBDII Diagnostic Tool HD V3.0
7
EN
3.1 Outline of HD V3.0
Figure 3-1
Table3-1：
No.
Name
Descriptions
①
Cable with OBD II
Connector
Connects the HD V3.0 to the vehicle‟s
Data Link Connector (DLC).
②
LCD display
Indicates test result
③
F1 Function button
In case of special use
④
F2 Function button
In case of special use
