Status Indication of Running Channel
Status
Status Indication
Status
Status indication
No display
No program, can select program to run
TRICK
Trickle charging status keeps a small current
for a while after finishing charging NiCd or
NiMH
STOPS
Stop status, press “stop” button to stop the
running program
MONITOR
Monitor status, only monitors the data
START
Start the program
FLOAT
Float charge, supports Pb battery
CHECK
Check status before running program
SYNCH.
Synchronous status, this channel runs with
another channel synchronously
CHARGE
Charge status
LOAD
Load status, this channel works on the load
control status of Channel regenerative
DISCHG
Discharge status
WAIT
Waiting status
PRE_C
Pre-charge, program will pre-charge when the
cell voltage is too low
CY_DE
Cycle delay status
KEEP
Keep charging status, keep charging for a while
after setting pre-charge
OVER!
Over status
BAL
Independent balance status. Only for balancing,
not charging the Li-battery,
ERROR
Error status
Status Indication of Channel Control
Status
Status Indication
Status
Status Indication
O.CV
Constant voltage status of output
I.CC
Constant current status of input current
B.CV
Constant voltage status of battery cells
I.CP
Constant status of input power
O.CC
Constant current status of output
O.AP
Total power regulation of output
C.CP
Constant power status of output
O.BV
Channel outputs voltage are imbalance in
Synchronous mode
C.TP
Temperature power reduce status
O.BC
Channel outputs current are imbalance in
Synchronous mode
I.CV
Constant status of input voltage
O.PC
Channel power containment regulation
status
