[CHASSIS PARTS]
REF ORDER
DESCRIPTION QTY.
NO. NO.
WS1 8970023671 SX2241 1.5DCOAXIALA-1 (1)/CH 1
WS2 8970023681 SX2241 1.5DCOAXIALB-1 (1)/CH 1
WS3 8970023691 SX2241 1.5DCOAXIALC-1 (1)/CH 1
J1 6510028410 MR-DS-01-1 <GA> 1
MF1 2710000520 SB0812H-ICOM-00 1
W1 8900015010 OPC-939B (P1N16L80) 1
W2 8900015101 OPC-940B-1 (P0.5N30L170) 1
W3 8900015101 OPC-940B-1 (P0.5N30L170) 1
W4 8900015110 OPC-941B (P1N16L170) 1
W5 8900015120 OPC-942B (P1N10L170) 1
EP1 8930021010 DOMED PLUG DP-500 1
EP4 0880001570 EX-1962 #32 (UT-106) [USA] 1
0880001570 EX-1962 #32 (UT-106) [USA-02] 1
MP1 8110007051 2241 L-COVER-1 Y2088A [USA] 1
8110007051 2241 L-COVER-1 Y2088A [EUR] 1
8110007050 2241 L-COVER [ITA] 1
8110007051 2241 L-COVER-1 Y2088A [FRA] 1
8110007050 2241 L-COVER [ESP] 1
8110007051 2241 L-COVER-1 Y2088A [DEN] 1
8110007051 2241 L-COVER-1 Y2088A [OTH] 1
8110007051 2241 L-COVER-1 Y2088A [CHN] 1
8110007051 2241 L-COVER-1 Y2088A [KOR] 1
8110007051 2241 L-COVER-1 Y2088A [USA-01] 1
8110007051 2241 L-COVER-1 Y2088A [CHN-01] 1
8110007051 2241 L-COVER-1 Y2088A [USA-02] 1
8110007051 2241 L-COVER-1 Y2088A [EUR-01] 1
8110007051 2241 L-COVER-1 Y2088A [ITA-01] 1
8110007051 2241 L-COVER-1 Y2088A [FRA-01] 1
8110007051 2241 L-COVER-1 Y2088A [ESP-01] 1
8110007051 2241 L-COVER-1 Y2088A [DEN-01] 1
8110007051 2241 L-COVER-1 Y2088A [OTH-01] 1
8110007051 2241 L-COVER-1 Y2088A [CHN-02] 1
8110007051 2241 L-COVER-1 Y2088A [KOR-01] 1
8110007051 2241 L-COVER-1 Y2088A [USA-03] 1
8110007051 2241 L-COVER-1 Y2088A [CHN-03] 1
MP2 8110007063 2241 U-COVER-3 Y2089C 1
MP3 8010018023 2241 CHASSIS-3 <STM> 1
MP4 8930037001 1691 EARTH PLATE-1 Y266A 1
MP6 8930002900 RUBBER LEG (A) SK1912A 2
MP7 8010001520 STAND (C) 1
MP8 8930005790 STAND (A) 1
MP9 8930005800 STAND (B) 1
MP10 8930018520 TR CRIP (A) 1
MP11 8930018520 TR CRIP (A) 1
MP12 8810009651 FLAT BT M3 X 8 NI-ZC3 4
MP13 8810008661 PHBT M3 X 8 NI-ZC3 2
MP14 8810008661 PHBT M3 X 8 NI-ZC3 5
MP15 8810008661 PHBT M3 X 8 NI-ZC3 7
MP16 8810008661 PHBT M3 X 8 NI-ZC3 6
MP17 8810008661 PHBT M3 X 8 NI-ZC3 9
MP18 8810008661 PHBT M3 X 8 NI-ZC3 4
MP19 8810008661 PHBT M3 X 8 NI-ZC3 1
MP20 8810003171 SET SCREWA M3 X 8 ZC3 6
MP21 8820000551 CAPBOLT M4 X 8 ZK3 4
MP22 8810005771 BIND M3 X 8 ZK3BLACK 14
MP23 8820000530 FLANGE BOLT M4 X 8 NI 1
MP24 8850000140 FLAT WASHER M 4 NI BS 2
MP25 8850000430 S-WASHER M 4 NI 1
MP26 8930052550 2241 SHEET 2
MP28 8810009131 PHBT M3 X12 NI-ZC3 2
MP29 8930052080 2241 EARTH SPRING 2
MP31 8930007120 THERMAL SHEET B 2
MP32 8930028840 SPONGE (DF) 2
MP33 8930004071 EARTH SPRING (C)-1 (SX-166) [USA] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [OTH] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [CHN] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [KOR] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [USA-01] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [CHN-01] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [USA-02] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [OTH-01] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [CHN-02] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [KOR-01] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [USA-03] 1
8930004071 EARTH SPRING (C)-1 (SX-166) [CHN-03] 1
[CHASSIS PARTS]
REF ORDER
DESCRIPTION QTY.
NO. NO.
MP35 8930053610 2242 EARTH SPRING [EUR] 1
8930053610 2242 EARTH SPRING [ITA] 1
8930053610 2242 EARTH SPRING [FRA] 1
8930053610 2242 EARTH SPRING [ESP] 1
8930053610 2242 EARTH SPRING [DEN] 1
8930053610 2242 EARTH SPRING [EUR-01] 1
8930053610 2242 EARTH SPRING [ITA-01] 1
8930053610 2242 EARTH SPRING [FRA-01] 1
8930053610 2242 EARTH SPRING [ESP-01] 1
8930053610 2242 EARTH SPRING [DEN-01] 1
MP36 8930053610 2242 EARTH SPRING [EUR] 1
8930053610 2242 EARTH SPRING [ITA] 1
8930053610 2242 EARTH SPRING [FRA] 1
8930053610 2242 EARTH SPRING [ESP] 1
8930053610 2242 EARTH SPRING [DEN] 1
8930053610 2242 EARTH SPRING [EUR-01] 1
8930053610 2242 EARTH SPRING [ITA-01] 1
8930053610 2242 EARTH SPRING [FRA-01] 1
8930053610 2242 EARTH SPRING [ESP-01] 1
8930053610 2242 EARTH SPRING [DEN-01] 1
MP37 8510013372 2242 SHIELD COVER-2 [EUR] 1
8510013372 2242 SHIELD COVER-2 [ITA] 1
8510013372 2242 SHIELD COVER-2 [FRA] 1
8510013372 2242 SHIELD COVER-2 [ESP] 1
8510013372 2242 SHIELD COVER-2 [DEN] 1
8510013372 2242 SHIELD COVER-2 [EUR-01] 1
8510013372 2242 SHIELD COVER-2 [ITA-01] 1
8510013372 2242 SHIELD COVER-2 [FRA-01] 1
8510013372 2242 SHIELD COVER-2 [ESP-01] 1
8510013372 2242 SHIELD COVER-2 [DEN-01] 1
MP38 8810008661 PHBT M3 X 8 NI-ZC3 [USA] 5
8810008661 PHBT M3 X 8 NI-ZC3 [EUR] 10
8810008661 PHBT M3 X 8 NI-ZC3 [ITA] 10
8810008661 PHBT M3 X 8 NI-ZC3 [FRA] 10
8810008661 PHBT M3 X 8 NI-ZC3 [ESP] 10
8810008661 PHBT M3 X 8 NI-ZC3 [DEN] 10
8810008661 PHBT M3 X 8 NI-ZC3 [OTH] 5
8810008661 PHBT M3 X 8 NI-ZC3 [CHN] 5
8810008661 PHBT M3 X 8 NI-ZC3 [KOR] 5
8810008661 PHBT M3 X 8 NI-ZC3 [USA-01] 5
8810008661 PHBT M3 X 8 NI-ZC3 [CHN-01] 5
8810008661 PHBT M3 X 8 NI-ZC3 [USA-02] 5
8810008661 PHBT M3 X 8 NI-ZC3 [EUR-01] 10
8810008661 PHBT M3 X 8 NI-ZC3 [ITA-01] 10
8810008661 PHBT M3 X 8 NI-ZC3 [FRA-01] 10
8810008661 PHBT M3 X 8 NI-ZC3 [ESP-01] 10
8810008661 PHBT M3 X 8 NI-ZC3 [DEN-01] 10
8810008661 PHBT M3 X 8 NI-ZC3 [OTH-01] 5
8810008661 PHBT M3 X 8 NI-ZC3 [CHN-02] 5
8810008661 PHBT M3 X 8 NI-ZC3 [KOR-01] 5
8810008661 PHBT M3 X 8 NI-ZC3 [USA-03] 5
8810008661 PHBT M3 X 8 NI-ZC3 [CHN-03] 5
MP40 8510013471 2241 PA COVER-1 [USA] 1
8510013471 2241 PA COVER-1 [OTH] 1
8510013471 2241 PA COVER-1 [CHN] 1
8510013471 2241 PA COVER-1 [KOR] 1
8510013471 2241 PA COVER-1 [USA-01] 1
8510013471 2241 PA COVER-1 [CHN-01] 1
8510013471 2241 PA COVER-1 [USA-02] 1
8510013471 2241 PA COVER-1 [OTH-01] 1
8510013471 2241 PA COVER-1 [CHN-02] 1
8510013471 2241 PA COVER-1 [KOR-01] 1
8510013471 2241 PA COVER-1 [USA-03] 1
8510013471 2241 PA COVER-1 [CHN-03] 1
SECTION 7
.
MECHANICAL PARTS
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
