7 - 3
[PA UNIT]
[FILTER UNIT]
[FRONT UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
REF ORDER
DESCRIPTION
QTY.
NO. NO.
REF ORDER
DESCRIPTION
QTY.
NO. NO.
WS1 8600036631 SX2242 J01*14*15*16*17PA-1 1 1
WS2 8600036641 SX2242 J12*13PA-1 50MM 1
J3* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN) 1
J6 6510028210 SJ050010 (TMP-J01X-V6) 1
J7 6510028210 SJ050010 (TMP-J01X-V6) 1
F1 5210000131 FGB 4A PBF (FGB0 125V) 1
F2 5220000230 S-N5054 #01 1
F3 5220000230 S-N5054 #01 1
MP1 8510013440 2242 EARTH PLATE Y553 [EUR] 1
8510013440 2242 EARTH PLATE Y553 [ITA] 1
8510013440 2242 EARTH PLATE Y553 [FRA] 1
8510013440 2242 EARTH PLATE Y553 [ESP] 1
8510013440 2242 EARTH PLATE Y553 [DEN] 1
8510013440 2242 EARTH PLATE Y553 [EUR-01] 1
8510013440 2242 EARTH PLATE Y553 [ITA-01] 1
8510013440 2242 EARTH PLATE Y553 [FRA-01] 1
8510013440 2242 EARTH PLATE Y553 [ESP-01] 1
8510013440 2242 EARTH PLATE Y553 [DEN-01] 1
MP4 8860001450 2178 RUG 2
W5* 7030008240 ERJ12Y0R00U 1
W72* 7030003860 ERJ3GE JPW V 1
W73* 7030003860 ERJ3GE JPW V 1
J1 6510022631 10FMN-BTRK-A (LF) (SN) 1
J2 6510028210 SJ050010 (TMP-J01X-V6) 1
J3 6510028210 SJ050010 (TMP-J01X-V6) 1
J4 6910001040 IPS-1136 1
J5 6910001040 IPS-1136 1
W2 9001502002 72/98/030/X98/X98 [USA] 1
9001502002 72/98/030/X98/X98 [EUR] 1
9037901027 73/98/030/X98/X98 [ITA] 1
9001502002 72/98/030/X98/X98 [FRA] 1
9001502002 72/98/030/X98/X98 [ESP] 1
9037901027 73/98/030/X98/X98 [DEN] 1
9001502002 72/98/030/X98/X98 [OTH] 1
9037901027 73/98/030/X98/X98 [CHN] 1
9037901027 73/98/030/X98/X98 [KOR] 1
9037901027 73/98/030/X98/X98 [USA-01] 1
9001502002 72/98/030/X98/X98 [CHN-01] 1
9001502002 72/98/030/X98/X98 [USA-02] 1
9001502002 72/98/030/X98/X98 [EUR-01] 1
9001502002 72/98/030/X98/X98 [ITA-01] 1
9001502002 72/98/030/X98/X98 [FRA-01] 1
9001502002 72/98/030/X98/X98 [ESP-01] 1
9001502002 72/98/030/X98/X98 [DEN-01] 1
9001502002 72/98/030/X98/X98 [OTH-01] 1
9001502002 72/98/030/X98/X98 [CHN-02] 1
9001502002 72/98/030/X98/X98 [KOR-01] 1
9001502002 72/98/030/X98/X98 [USA-03] 1
9001502002 72/98/030/X98/X98 [CHN-03] 1
W3 6910001031 IPS-1041-4-PT 1
W4 6910001031 IPS-1041-4-PT 1
MP4 8860001450 2178 RUG [USA-01] only 2
MP1 8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [USA] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [EUR] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [ITA] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [ESP] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [DEN] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [OTH] only 1
8210024110 2241 FRONT PANEL (B) ASSEMBLY-2 [CHN] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [KOR] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [USA-01] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [CHN-01] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [USA-02] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [EUR-01] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [ITA-01] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [FRA-01] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [ESP-01] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [DEN-01] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [OTH-01] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [CHN-02] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [KOR-01] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [USA-03] only 1
8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 [CHN-03] only 1
MP6 8010018051 2241 SUB CHASSIS ASSEMBLY-1 [USA] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [EUR] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [ITA] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [ESP] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [DEN] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [OTH] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [CHN] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [KOR] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [USA-01] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [CHN-01] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [USA-02] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [EUR-01] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [ITA-01] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [FRA-01] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [ESP-01] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [DEN-01] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [OTH-01] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [CHN-02] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [KOR-01] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [USA-03] only 1
8010018051 2241 SUB CHASSIS ASSEMBLY-1 [CHN-03] only 1
MP15 8610014310 KNOB N-283A ASSEMBLY 1
WS1 8970023640 SX2242 ICOM SHIELD (1)/FR 1
SP1 2510000671 VS-C50-0827 1
W3 8900014740 OPC-885A (P1N10L39) 1
W4 8900014740 OPC-885A (P1N10L39) 1
W5 8900014730 OPC-683A (P1N10L110) 1
EP1 6910012480 RMS20-250-201-1R [USA] 1
6910012480 RMS20-250-201-1R [EUR] 1
6910012480 RMS20-250-201-1R [ITA] 1
6910012480 RMS20-250-201-1R [FRA] 1
6910012480 RMS20-250-201-1R [ESP] 1
6910012480 RMS20-250-201-1R [DEN] 1
6910012480 RMS20-250-201-1R [OTH] 1
6910012480 RMS20-250-201-1R [CHN] 1
6910012480 RMS20-250-201-1R [KOR] 1
6910012480 RMS20-250-201-1R [USA-01] 1
6910012480 RMS20-250-201-1R [CHN-01] 1
0880001360 EX-2500 #02 SENSOR [USA-02] 1
0880001360 EX-2500 #02 SENSOR [EUR-01] 1
0880001360 EX-2500 #02 SENSOR [ITA-01] 1
0880001360 EX-2500 #02 SENSOR [FRA-01] 1
0880001360 EX-2500 #02 SENSOR [ESP-01] 1
0880001360 EX-2500 #02 SENSOR [DEN-01] 1
0880001360 EX-2500 #02 SENSOR [OTH-01] 1
0880001360 EX-2500 #02 SENSOR [CHN-02] 1
0880001360 EX-2500 #02 SENSOR [KOR-01] 1
0880001360 EX-2500 #02 SENSOR [USA-03] 1
0880001360 EX-2500 #02 SENSOR [CHN-03] 1
EP2 6450001230 HLJ0999-01-480 SNAP PLATE 2 1
MP1 8210016661 2241 FRONT PANEL (A)-1 [FRA] only 1
MP2 8930051400 2241 21-KEY (A) <SEP> 1
MP3 8930050930 2241 3-KEY <SEP> 1
MP4 8930050960 2241 POWER KEY <SEP> 1
MP5 8930050950 2241 LOCK KEY <SEP> 1
MP6 8010018001 2241 SUB CHASSIS-1 [FRA] only 1
MP7 8930050981 2241 PHONE HOLDER-1 [FRA] only 1
MP9 8610010420 KNOB N261 1
MP10 8610010420 KNOB N261 1
MP11 8610010710 KNOB N272 1
MP12 8610010710 KNOB N272 1
MP18 8610009171 KNOB N-213 COVER-1 (TOP)S 1
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
