[MAIN UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
WS1 8970023610 SX2242 ICOM SIELD (1)/MA 1
WS2 8970023660 SX2242 (2)/MA [EUR] 1
8970023660 SX2242 (2)/MA [ITA] 1
W801* 7030003860 ERJ3GE JPW V 1
W1202* 7030003860 ERJ3GE JPW V 1
W1311* 7030003860 ERJ3GE JPW V 1
W1726* 7030003860 ERJ3GE JPW V 1
W2101* 7030003860 ERJ3GE JPW V 1
W2201* 7030003860 ERJ3GE JPW V 1
W2351* 7030003860 ERJ3GE JPW V 1
W3601* 7030003860 ERJ3GE JPW V 1
W4216* 7030003860 ERJ3GE JPW V 1
W4401* 7030003860 ERJ3GE JPW V 1
W4801* 7030003860 ERJ3GE JPW V [USA] 1
7030003860 ERJ3GE JPW V [OTH] 1
7030003860 ERJ3GE JPW V [CHN] 1
7030003860 ERJ3GE JPW V [KOR] 1
7030003860 ERJ3GE JPW V [USA-01] 1
7030003860 ERJ3GE JPW V [CHN-01] 1
7030003860 ERJ3GE JPW V [USA-02] 1
7030003860 ERJ3GE JPW V [OTH-01] 1
7030003860 ERJ3GE JPW V [CHN-02] 1
7030003860 ERJ3GE JPW V [KOR-01] 1
7030003860 ERJ3GE JPW V [USA-03] 1
7030003860 ERJ3GE JPW V [CHN-03] 1
W4802* 7030003860 ERJ3GE JPW V [USA] 1
7030003860 ERJ3GE JPW V [OTH] 1
7030003860 ERJ3GE JPW V [CHN] 1
7030003860 ERJ3GE JPW V [KOR] 1
7030003860 ERJ3GE JPW V [USA-01] 1
7030003860 ERJ3GE JPW V [CHN-01] 1
7030003860 ERJ3GE JPW V [USA-02] 1
7030003860 ERJ3GE JPW V [OTH-01] 1
7030003860 ERJ3GE JPW V [CHN-02] 1
7030003860 ERJ3GE JPW V [KOR-01] 1
7030003860 ERJ3GE JPW V [USA-03] 1
7030003860 ERJ3GE JPW V [CHN-03] 1
W4803* 7030003860 ERJ3GE JPW V [USA] 1
7030003860 ERJ3GE JPW V [OTH] 1
7030003860 ERJ3GE JPW V [CHN] 1
7030003860 ERJ3GE JPW V [KOR] 1
7030003860 ERJ3GE JPW V [USA-01] 1
7030003860 ERJ3GE JPW V [CHN-01] 1
7030003860 ERJ3GE JPW V [USA-02] 1
7030003860 ERJ3GE JPW V [OTH-01] 1
7030003860 ERJ3GE JPW V [CHN-02] 1
7030003860 ERJ3GE JPW V [KOR-01] 1
7030003860 ERJ3GE JPW V [USA-03] 1
7030003860 ERJ3GE JPW V [CHN-03] 1
J1 6510028210 SJ050010 (TMP-J01X-V6) 1
J201* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J401* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J701 6510028210 SJ050010 (TMP-J01X-V6) 1
J2001* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J2501* 6510019191 52365-0871 1
J2602* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J2603* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J3601 6510003391 B03B-EH-S (LF) (SN) 1
J4001* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J4101* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN) 1
J4201* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J4401* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J4501 6450000140 HSJ0807-01-010 1
J4502* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J4651 6510024661 TCS5072-1041577 1
J4801 6450001130 JPJ2042-01-110 1
J5001 6450000140 HSJ0807-01-010 1
J5101 6510028070 01J0377-00 1
MP1 8510013040 2241 MIXER CASE 1
MP2 8930017191 EARTH SPRING (F)-1 [EUR] 1
8930017191 EARTH SPRING (F)-1 [ITA] 1
8930017191 EARTH SPRING (F)-1 [FRA] 1
8930017191 EARTH SPRING (F)-1 [ESP] 1
8930017191 EARTH SPRING (F)-1 [DEN] 1
8930017191 EARTH SPRING (F)-1 [EUR-01] 1
8930017191 EARTH SPRING (F)-1 [ITA-01] 1
8930017191 EARTH SPRING (F)-1 [FRA-01] 1
8930017191 EARTH SPRING (F)-1 [ESP-01] 1
8930017191 EARTH SPRING (F)-1 [DEN-01] 1
MP3 8930049131 SHIELD TAPE (D)-1 [EUR] 1
8930049131 SHIELD TAPE (D)-1 [ITA] 1
8930049131 SHIELD TAPE (D)-1 [FRA] 1
8930049131 SHIELD TAPE (D)-1 [ESP] 1
8930049131 SHIELD TAPE (D)-1 [DEN] 1
8930049131 SHIELD TAPE (D)-1 [EUR-01] 1
8930049131 SHIELD TAPE (D)-1 [ITA-01] 1
8930049131 SHIELD TAPE (D)-1 [FRA-01] 1
8930049131 SHIELD TAPE (D)-1 [ESP-01] 1
8930049131 SHIELD TAPE (D)-1 [DEN-01] 1
MP25 8510013140 2241 DC-A CASE 1
MP301 8930005320 FILTER SPACER 2
[MAIN UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
MP4801 8930053600 2242 SPRING [EUR] 1
8930053600 2242 SPRING [ITA] 1
8930053600 2242 SPRING [FRA] 1
8930053600 2242 SPRING [ESP] 1
8930053600 2242 SPRING [DEN] 1
8930053600 2242 SPRING [EUR-01] 1
8930053600 2242 SPRING [ITA-01] 1
8930053600 2242 SPRING [FRA-01] 1
8930053600 2242 SPRING [ESP-01] 1
8930053600 2242 SPRING [DEN-01] 1
[PLL UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
WS1 8970023890 SX2241 0.8DCOAXIALA (1)/PL [USA] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [EUR] 1
8970023870 SX2242 0.8DCOAXIALA (1)/PL [ITA] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [FRA] 1
8970023870 SX2242 0.8DCOAXIALA (1)/PL [ESP] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [DEN] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [OTH] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [CHN] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [KOR] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [USA-01] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [CHN-01] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [USA-02] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [EUR-01] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [ITA-01] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [FRA-01] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [ESP-01] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [DEN-01] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [OTH-01] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [CHN-02] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [KOR-01] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [USA-03] 1
8970023890 SX2241 0.8DCOAXIALA (1)/PL [CHN-03] 1
WS2 8970023630 SX2242 ICOM SHIELD (1)/PL 1
WS3 8970025370 SX2242 0.8D COAXIALB (1)/PL [USA] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [EUR] 1
8970023880 SX2242 0.8DCOAXIALB (1)/PL [ITA] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [FRA] 1
8970023880 SX2242 0.8DCOAXIALB (1)/PL [ESP] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [DEN] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [OTH] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [CHN] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [KOR] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [USA-01] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [CHN-01] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [USA-02] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [EUR-01] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [ITA-01] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [FRA-01] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [ESP-01] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [DEN-01] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [OTH-01] 1
8970023900 SX2241 0.8DCOAXIALB (1)/PL [CHN-02] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [KOR-01] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [USA-03] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [CHN-03] 1
W1* 7030003860 ERJ3GE JPW V 1
W7* 7030003860 ERJ3GE JPW V 1
W9* 7030003860 ERJ3GE JPW V 1
W10* 7030003860 ERJ3GE JPW V 1
W92* 7030003860 ERJ3GE JPW V 1
W170* 7030003860 ERJ3GE JPW V 1
J1* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J3* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN) 1
J4* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
MP101 8950000180 CABLE TIE -80 (DENNISON DS-80) [CHN-01] only 2
MP102 8950000180 CABLE TIE -80 (DENNISON DS-80) [CHN-01] only 2
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
