Icom IC-718 Service Manual Addendum

(Replacement page)
January 2013
7 - 2
[PLL UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
WS1 8970023890 SX2241 0.8D COAXIALA (1)/PL 1
WS2 8970023630 SX2242 ICOM SIELD (1)/PL 1
WS3 8970025370 SX2242 0.8D COAXIALB (1)/PL [USA-02] 1
8970023900 SX2241 0.8D COAXIALB (1)/PL [EUR-01] 1
8970023900 SX2241 0.8D COAXIALB (1)/PL [ITA-01] 1
8970023900 SX2241 0.8D COAXIALB (1)/PL [FRA-01] 1
8970023900 SX2241 0.8D COAXIALB (1)/PL [ESP-01] 1
8970023900 SX2241 0.8D COAXIALB (1)/PL [DEN-01] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [OTH-01] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [KOR-01] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [USA-03] 1
8970025370 SX2242 0.8D COAXIALB (1)/PL [CHN-03] 1
W1* 7030003860 ERJ3GE JPW V 1
W7* 7030003860 ERJ3GE JPW V 1
W9* 7030003860 ERJ3GE JPW V 1
W10* 7030003860 ERJ3GE JPW V 1
W92* 7030003860 ERJ3GE JPW V 1
W170* 7030003860 ERJ3GE JPW V 1
J1* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J3* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN) 1
J4* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
[PA UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
WS1 8600036631 SX2242 J01*14*15*16*17PA-1 1 1
WS2 8600036641 SX2242 J12*13PA-1 50MM 1
J3* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN) 1
J6 6510028210 SJ050010 (TMP-J01X-V6) 1
J7 6510028210 SJ050010 (TMP-J01X-V6) 1
F1 5210000131 FGB 4A PBF (FGB0 125V) 1
F2 5220000230 S-N5054 #01 1
F3 5220000230 S-N5054 #01 1
MP1 8510013440 2242 EARTH PLATE Y553 [EUR-01] 1
8510013440 2242 EARTH PLATE Y553 [ITA-01] 1
8510013440 2242 EARTH PLATE Y553 [FRA-01] 1
8510013440 2242 EARTH PLATE Y553 [ESP-01] 1
8510013440 2242 EARTH PLATE Y553 [DEN-01] 1
MP4 8860001450 2178 RUG 2
[FILTER UNIT]
[FRONT UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
W5* 7030008240 ERJ12Y0R00U 1
W72* 7030003860 ERJ3GE JPW V 1
W73* 7030003860 ERJ3GE JPW V 1
J1 6510022631 10FMN-BTRK-A (LF) (SN) 1
J2 6510028210 SJ050010 (TMP-J01X-V6) 1
J3 6510028210 SJ050010 (TMP-J01X-V6) 1
J4 6910001040 IPS-1136 1
J5 6910001040 IPS-1136 1
W2 9001502002 72/98/030/X98/X98 1
W3 6910001031 IPS-1041-4-PT 1
W4 6910001031 IPS-1041-4-PT 1
MP1 8210024120 2241 FRONT PANEL (A) ASSEMBLY-2 1
MP6 8010018051 2241 SUB CHASSIS ASSEMBLY-1 1
MP15 8610014310 KNOB N-283A ASSEMBLY 1
WS1 8970023640 SX2242 ICOM SIELD (1) 1
SP1 2510000671 VS-C50-0827 1
W3 8900014740 OPC-885A (P1N10L39) 1
W4 8900014740 OPC-885A (P1N10L39) 1
W5 8900014730 OPC-683A (P1N10L110) 1
EP1 0880001360 EX-2500 #02 SENSOR 1
EP2 6450001230 HLJ0999-01-480 SNAP PLATE 1
MP2 8930051400 2241 21-KEY (A) <SEP> 1
MP3 8930050930 2241 3-KEY <SEP> 1
MP4 8930050960 2241 POWER KEY <SEP> 1
MP5 8930050950 2241 LOCK KEY <SEP> 1
MP9 8610010420 KNOB N261 1
MP10 8610010420 KNOB N261 1
MP11 8610010710 KNOB N272 1
MP12 8610010710 KNOB N272 1
MP18 8610009171 KNOB N-213 COVER-1 (TOP) 1
MP22 8810008661 PHBT M3 X 8 NI-ZC3 5
MP23 8810009131 PHBT M3 X12 NI-ZC3 6
MP25 8930036870 SPONGE (DZ) 1
MP31 8930071480 2242 JACK RUBBER (TOT) 1
MP32 8930071490 2242 F-SPONGE 2
MP34 8930072980 INSULATION SHEET (LW) 2
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[VR UNIT]
[MIC UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510022051 10FM-1.0SP-1.9-TF (LF) (SN) 1
J1* 6510000191 FM214-8SS (P)-1 1
J2* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
[PHONE UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510028020 01J0376-00 1
J2* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
[LOGIC-A UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
W1* 7030003860 ERJ3GE JPW V 1
W70* 7030003860 ERJ3GE JPW V 1
W101* 7030003860 ERJ3GE JPW V 1
W102* 7030003860 ERJ3GE JPW V 1
J1* 6510020421 S4B-PH-SM4-TB (LF) (SN) 1
J3* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J4* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J5* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J6* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J7* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J9* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN) 1
DS1 5030002490 A0087A LCD83.5*45.5*1.1T LCD 1
EP70 8930051450 SRCN-2241-SP-N-W (SHJ) 2
MP1 8210016610 2241 REFLECTOR 1
MP3 8930051090 2241 LCD FILTER 1
MP4 8930072670 2241 LCD RUBBER ASSEMBLY (TOP) 1
