Icom IC-718

Jun. 2011
1
SECTION 5
.
PARTS LIST
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
IC1 1110004080 S.IC UPC2709T-E3
IC1701 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC1751 1110002700 S.IC NJM2904M-TE1-#FMZB
IC2001 1110004870 S.IC TA4101F (TE12L.F)
IC2101 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC2102 1130005641 S.IC TC4W53F(TE12L,F)
IC2201 1140005281 S.IC UPC5023GS-077-E1-A
IC2301 1110004840 S.IC NJM1496V-TE1-#ZZZB
IC2351 1110002700 S.IC NJM2904M-TE1-#FMZB
IC2701 1110003300 S.IC M5282FP 70CD
IC2702 1110001811 S.IC TA7368FG(5,ER)
IC2801 1130004201 S.IC TC4S66F(TE85R,F)
IC2901 1110003091 IC LA4425A-E
IC3001 1130007700 S.IC BU4094BCF-E2
IC3002 1160000132 S.IC TD62783AFG(O,S,EL)
IC3003 1160000132 S.IC TD62783AFG(O,S,EL)
IC3004 1130007700 S.IC BU4094BCF-E2
IC3005 1160000132 S.IC TD62783AFG(O,S,EL)
IC3006 1130007700 S.IC BU4094BCF-E2
IC3301 1110004310 S.IC M62352GP 75EC
IC3401 1110002031 IC TA7808S(Q)
IC3501 1110001401 S.IC UPC1555G2-E1-A
Q101 1580000620 S.FET 3SK131-T2 MAS
Q102 1580000620 S.FET 3SK131-T2 MAS
Q151 1560001420 S.FET 2SK882-GR T5LICOMF
Q201 1530003151 S.TRA 2SC4673D-TD-E
Q501 1590002310 S.TRA DTC114EE TL
Q502 1560001420 S.FET 2SK882-GR T5LICOMF
Q503 1590002310 S.TRA DTC114EE TL
Q511 1590002310 S.TRA DTC114EE TL
Q701 1590002310 S.TRA DTC114EE TL
Q1001 1510000510 S.TRA 2SA1576A T106R
Q1002 1590002310 S.TRA DTC114EE TL
Q1101 1560000641 S.FET 2SK1740-4/5-TB-E
Q1102 1560000641 S.FET 2SK1740-4/5-TB-E
Q1103 1560000641 S.FET 2SK1740-4/5-TB-E
Q1104 1560000641 S.FET 2SK1740-4/5-TB-E
Q1201 1580000620 S.FET 3SK131-T2 MAS
Q1301 1580000620 S.FET 3SK131-T2 MAS
Q1401 1560000721 S.FET 2SK2171-4-TD-E
Q1402 1560000721 S.FET 2SK2171-4-TD-E
Q1501 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1502 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1503 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1504 1530002060 S.TRA 2SC4081 T106 R
Q1505 1510000510 S.TRA 2SA1576A T106R
Q1506 1590002310 S.TRA DTC114EE TL
Q1507 1530002060 S.TRA 2SC4081 T106 R
Q1508 1530002060 S.TRA 2SC4081 T106 R
Q1509 1590001870 S.TRA DTA114EE TL
Q1601 1530002060 S.TRA 2SC4081 T106 R
Q1602 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1603 1580000620 S.FET 3SK131-T2 MAS
Q1611 1530002060 S.TRA 2SC4081 T106 R
Q1703 1510000510 S.TRA 2SA1576A T106R
Q1705 1590002310 S.TRA DTC114EE TL
Q1706 1590002310 S.TRA DTC114EE TL
Q1801 1590001540 S.TRA UMD6N TR
Q1802 1590001540 S.TRA UMD6N TR
Q1803 1590001540 S.TRA UMD6N TR
Q1805 1530002060 S.TRA 2SC4081 T106 R
Q2302 1590002310 S.TRA DTC114EE TL
Q2381 1530002060 S.TRA 2SC4081 T106 R
Q2383 1590002310 S.TRA DTC114EE TL
Q2384 1590002310 S.TRA DTC114EE TL
Q3101 1590002310 S.TRA DTC114EE TL
Q3601 1540000550 S.TRA 2SD1664 T100Q
Q3701 1590002310 S.TRA DTC114EE TL
Q3702 1590001870 S.TRA DTA114EE TL
Q3801 1590002310 S.TRA DTC114EE TL
Q3802 1590001870 S.TRA DTA114EE TL
Q4601 1540000441 S.TRA 2SD1619T-TD-E
Q4801 1590002310 S.TRA DTC114EE TL
D201 1790000620 S.DIO MA77(TX)
D202 1790000620 S.DIO MA77(TX)
D301 1790000620 S.DIO MA77(TX)
D302 1790000620 S.DIO MA77(TX)
D303 1790000620 S.DIO MA77(TX)
D304 1790000620 S.DIO MA77(TX)
D305 1790000620 S.DIO MA77(TX)
D306 1790000620 S.DIO MA77(TX)
D401 1750000431 S.DIO HSB88WSTR-E
D501 1160000070 S.DIO DAN202K T146
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
D502 1790001251 S.DIO MA2S1110GL [USA]
1790001251 S.DIO MA2S1110GL [EUR]
1790001251 S.DIO MA2S1110GL [ITA]
1790001251 S.DIO MA2S1110GL [FRA]
1790001251 S.DIO MA2S1110GL [ESP]
1790001251 S.DIO MA2S1110GL [DEN]
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [KOR]
1790001251 S.DIO MA2S1110GL [USA-01]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [USA-02]
1750002020 S.DIO DA2S10100L [EUR-01]
1750002020 S.DIO DA2S10100L [ITA-01]
1750002020 S.DIO DA2S10100L [FRA-01]
1750002020 S.DIO DA2S10100L [ESP-01]
1750002020 S.DIO DA2S10100L [DEN-01]
1750002020 S.DIO DA2S10100L [OTH-01]
1750002020 S.DIO DA2S10100L [KOR-01]
1750002020 S.DIO DA2S10100L [USA-03]
1750002020 S.DIO DA2S10100L [CHN-03]
D503 1160000070 S.DIO DAN202K T146
D601 1160000080 S.DIO DAP202K T146
D602 1160000070 S.DIO DAN202K T146
D603 1160000080 S.DIO DAP202K T146
D604 1160000070 S.DIO DAN202K T146
D605 1160000080 S.DIO DAP202K T146
D606 1160000070 S.DIO DAN202K T146
D607 1160000080 S.DIO DAP202K T146
D608 1160000070 S.DIO DAN202K T146
D701 1750000641 S.DIO 1SV312(TE85L,F)
D801 1750000641 S.DIO 1SV312(TE85L,F)
D802 1750000641 S.DIO 1SV312(TE85L,F)
D803 1790000620 S.DIO MA77(TX)
D804 1790000620 S.DIO MA77(TX)
D805 1790000620 S.DIO MA77(TX)
D806 1790000620 S.DIO MA77(TX)
D807 1790000620 S.DIO MA77(TX)
D808 1790000620 S.DIO MA77(TX)
D809 1790000620 S.DIO MA77(TX)
D810 1790000620 S.DIO MA77(TX)
D811 1790000620 S.DIO MA77(TX)
D812 1790000620 S.DIO MA77(TX)
D813 1790000620 S.DIO MA77(TX)
D814 1790000620 S.DIO MA77(TX)
D815 1790000620 S.DIO MA77(TX)
D816 1790000620 S.DIO MA77(TX)
D901 1790000620 S.DIO MA77(TX)
D902 1790000620 S.DIO MA77(TX)
D903 1790000620 S.DIO MA77(TX)
D904 1790000620 S.DIO MA77(TX)
D1301 1790000620 S.DIO MA77(TX)
D1302 1790000620 S.DIO MA77(TX)
D1501 1790001211 S.DIO 1SS375-TL-E
D1503 1790001251 S.DIO MA2S1110GL [USA]
1790001251 S.DIO MA2S1110GL [EUR]
1790001251 S.DIO MA2S1110GL [ITA]
1790001251 S.DIO MA2S1110GL [FRA]
1790001251 S.DIO MA2S1110GL [ESP]
1790001251 S.DIO MA2S1110GL [DEN]
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [KOR]
1790001251 S.DIO MA2S1110GL [USA-01]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [USA-02]
1750002020 S.DIO DA2S10100L [EUR-01]
1750002020 S.DIO DA2S10100L [ITA-01]
1750002020 S.DIO DA2S10100L [FRA-01]
1750002020 S.DIO DA2S10100L [ESP-01]
1750002020 S.DIO DA2S10100L [DEN-01]
1750002020 S.DIO DA2S10100L [OTH-01]
1750002020 S.DIO DA2S10100L [KOR-01]
1750002020 S.DIO DA2S10100L [USA-03]
1750002020 S.DIO DA2S10100L [CHN-03]
D1510 1790001251 S.DIO MA2S1110GL [USA]
1790001251 S.DIO MA2S1110GL [EUR]
1790001251 S.DIO MA2S1110GL [ITA]
1790001251 S.DIO MA2S1110GL [FRA]
1790001251 S.DIO MA2S1110GL [ESP]
1790001251 S.DIO MA2S1110GL [DEN]
1790001251 S.DIO MA2S1110GL [OTH]
1790001251 S.DIO MA2S1110GL [KOR]
1790001251 S.DIO MA2S1110GL [USA-01]
1790001251 S.DIO MA2S1110GL [CHN-01]
1750002020 S.DIO DA2S10100L [USA-02]
1750002020 S.DIO DA2S10100L [EUR-01]
1750002020 S.DIO DA2S10100L [ITA-01]
1750002020 S.DIO DA2S10100L [FRA-01]
1750002020 S.DIO DA2S10100L [ESP-01]
1750002020 S.DIO DA2S10100L [DEN-01]
1750002020 S.DIO DA2S10100L [OTH-01]
1750002020 S.DIO DA2S10100L [KOR-01]
1750002020 S.DIO DA2S10100L [USA-03]
1750002020 S.DIO DA2S10100L [CHN-03]
D1631 1160000070 S.DIO DAN202K T146
D1632 1790000620 S.DIO MA77(TX)
D1701 1730002451 S.ZEN MAZ8043GHL
