5 - 16
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[RX-PLL-B UNIT]
Q1402 1530003021 S.TR 2SC4402-3-TL-E T 123.4/111.8
Q1403 1530003021 S.TR 2SC4402-3-TL-E T 123.4/114.3
Q1501 1530003450 S.TR 2SC4835-R (TX) T 133.5/143.5
Q1502 1530003450 S.TR 2SC4835-R (TX) T 120.4/143.5
Q1651 1530002601 S.TR 2SC4215-O (TE85R,F) B 105.6/140.3
Q1701 1590001960 S.TR XP4311 (TX) T 106.6/43.9
Q1702 1590001960 S.TR XP4311 (TX) T 148.9/147.2
Q1703 1590001960 S.TR XP4311 (TX) T 146.4/147.2
D101 1750000520 S.DIO DAN222TL T 41.8/86.2
D152 1720000590 S.VCP MA357 (TX) T 17.6/59.9
D153 1790000491 S.DIO HSM88ASTR-E T 27.2/60.4
D154 1790000491 S.DIO HSM88ASTR-E T 27.2/63.8
D201 1750000520 S.DIO DAN222TL T 32.4/34.1
D220 1720000590 S.VCP MA357 (TX) T 50.8/31.8
D221 1720000590 S.VCP MA357 (TX) T 52.9/31.8
D222 1790000620 S.DIO MA77 (TX) T 82.6/29.8
D230 1720000590 S.VCP MA357 (TX) T 50.8/44.2
D231 1720000590 S.VCP MA357 (TX) T 52.9/44.2
D232 1790000620 S.DIO MA77 (TX) T 82.6/42.3
D240 1720000590 S.VCP MA357 (TX) T 50.8/56.7
D241 1720000590 S.VCP MA357 (TX) T 52.9/56.7
D242 1790000620 S.DIO MA77 (TX) T 82.6/54.8
D250 1720000590 S.VCP MA357 (TX) T 50.8/69.2
D252 1790000620 S.DIO MA77 (TX) T 82.6/67.3
D261 1720000590 S.VCP MA357 (TX) T 52.9/81.7
D262 1790000620 S.DIO MA77 (TX) T 82.6/79.8
D270 1720000590 S.VCP MA357 (TX) T 50.8/94.2
D271 1720000590 S.VCP MA357 (TX) T 52.4/96.7
D272 1790000620 S.DIO MA77 (TX) T 82.5/92
D341 1790000620 S.DIO MA77 (TX) T 90/37.2
D342 1160000070 S.DIO DAN202K T146 B 81.1/47.7
D362 1790000620 S.DIO MA77 (TX) T 88.3/65.5
D363 1790000620 S.DIO MA77 (TX) T 88.3/62
D421 1790000620 S.DIO MA77 (TX) T 91.9/85
D441 1790000620 S.DIO MA77 (TX) T 89.6/74.4
D501 1750000520 S.DIO DAN222TL T 42/132
D542 1720000590 S.VCP MA357 (TX) T 62.5/139.6
D1101 1790000620 S.DIO MA77 (TX) T 177.6/146.6
D1102 1790000620 S.DIO MA77 (TX) T 177.6/148.4
D1351 1750000581 S.DIO 1SV307 (TPH3,F) T 140.8/71.1
D1653 1750000550 S.DIO 1SS355 TE-17 T 138.9/167.2
D1654 1750000550 S.DIO 1SS355 TE-17 T 142.5/167.2
D1701 1790001670 S.DIO RB706F-40T106 T 170.5/160.8
FI101 2020002090 S.CER SFECV10M7FD00-R0 T 26/73.9
FI1401 2030000321 S.MLH FL-359A (64.555 MHz) T 116.3/88.5
FI1402 2030000311 S.MLH FL-360A (64.555 MHz) T 107/88.5
FI1403 2030000520 S.MLH DSF753SDF T 126/85.5
L1 6200003261 S.COL NLV32T-101J T 10.8/15.4
L2 6200003261 S.COL NLV32T-101J T 29/19.9
L10 6200003950 S.COL HF50ACC 322513-T T 38.6/14.7
L11 6200003950 S.COL HF50ACC 322513-T T 13.8/15.4
L12 6200003950 S.COL HF50ACC 322513-T T 16.8/15.4
L13 6200003950 S.COL HF50ACC 322513-T T 29/15.4
L20 6200003321 S.COL NLV32T-3R3J T 85.9/123.8
L30 6200005491 S.COL NLV32T-331J T 20.6/120
L101 6200001831 S.COL NLV32T-100J T 38.3/72.8
L151 6130002970 COL LB-343
L152 6200001831 S.COL NLV32T-100J T 30/54.5
L201 6200005011 S.COL NLV25T-100J T 22.2/45
L211 6200003661 S.COL NLV25T-R68J B 45.4/35.3
L220 6200010790 S.COL C2520C-3R9G-A T 51.9/37.5
L221 6190001421 COL #E526GN-110502
L222 6200010790 S.COL C2520C-3R9G-A T 76.2/37.7
L230 6200010830 S.COL C2520C-3R3G-A T 51.9/50
L231 6190001421 COL #E526GN-110502
L232 6200010830 S.COL C2520C-3R3G-A T 76.2/50.2
L240 6200010830 S.COL C2520C-3R3G-A T 51.9/62.4
L241 6190001421 COL #E526GN-110502
L242 6200010830 S.COL C2520C-3R3G-A T 76.2/62.7
L250 6200010820 S.COL C2520C-2R7G-A T 51.9/74.9
L251 6190001421 COL #E526GN-110502
L252 6200010820 S.COL C2520C-2R7G-A T 76.2/75.2
L260 6200010820 S.COL C2520C-2R7G-A T 51.9/87.4
L261 6190001411 COL #E526GN-110501
L262 6200010820 S.COL C2520C-2R7G-A T 76.2/87.7
L270 6200010810 S.COL C2520C-2R2G-A T 51.9/99.8
L271 6190001411 COL #E526GN-110501
L272 6200010810 S.COL C2520C-2R2G-A T 76/100.2
L280 6200005011 S.COL NLV25T-100J T 67.4/25.5
L302 6200001831 S.COL NLV32T-100J T 89.3/42.6
L331 6200002641 S.COL NLV25T-R15J T 95.1/34.1
L332 6200002411 S.COL NLV25T-056J B 93.2/36
L341 6200003261 S.COL NLV32T-101J T 87/39.6
L351 6200001831 S.COL NLV32T-100J T 91.3/62
L421 6200008641 S.COL NLV32T-391J T 87/81
L441 6200002601 S.COL NLV25T-047J T 91.9/72.3
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[RXPLL-B UNIT]
L442 6200010730 S.COL C2520C-68NG-A T 90.5/78.2
L451 6200002641 S.COL NLV25T-R15J T 95/81
L452 6200003261 S.COL NLV32T-101J T 87/78
L501 6200001831 S.COL NLV32T-100J T 31/125.8
L530 6200003171 S.COL NLV32T-330J T 14.6/134.9
L531 6200003171 S.COL NLV32T-330J T 14.6/130.8
L532 6200003171 S.COL NLV32T-330J T 15.5/127.1
L541 6200010790 S.COL C2520C-3R9G-A T 56.3/139.6
L542 6190001421 COL #E526GN-110502
L543 6200010790 S.COL C2520C-3R9G-A T 68.4/147.9
L544 6200003261 S.COL NLV32T-101J B 65.9/142.1
L545 6200003261 S.COL NLV32T-101J B 51.3/139.6
L561 6200003261 S.COL NLV32T-101J B 64/156
L562 6200001831 S.COL NLV32T-100J B 74.6/151.8
L565 6150004250 COL LS-471A (C-14922)
L566 6150004250 COL LS-471A (C-14922)
L591 6200007790 S.COL LQW2BHNR15J03L T 60.5/171.5
L601 6200001831 S.COL NLV32T-100J T 49.5/123.6
L602 6200002641 S.COL NLV25T-R15J T 54.1/118
L603 6200002841 S.COL NLV25T-R22J T 57.1/117.2
L651 6200001831 S.COL NLV32T-100J T 15.5/176.2
L681 6200002981 S.COL NLV32T-R56J T 37.4/176.2
L682 6200003041 S.COL NLV32T-R68J T 37.8/172.6
L683 6200003051 S.COL NLV32T-R82J T 40.2/166.2
L701 6200003261 S.COL NLV32T-101J T 23.6/120
L702 6150004971 S.COL LS-522-LF T 37.6/108.6
L703 6150004971 S.COL LS-522-LF T 37.5/118.5
L1001 6190001650 COL ELC06D102E
L1002 6140004400 COL LR-499
L1004 6140003890 COL LR-488
L1005 6180001000 COL LAL 04NA 102K
L1006 6140003900 COL LR-489
L1007 6140003800 COL LR-439
L1008 6190001650 COL ELC06D102E
L1009 6190001650 COL ELC06D102E
L1010 6140003880 COL LR-486
L1011 6140003880 COL LR-486
L1012 6140003800 COL LR-439
L1013 6200010680 S.COL C2520C-R22G-A T 155/55.2
L1014 6200010680 S.COL C2520C-R22G-A T 157.9/12.4
L1015 6200007790 S.COL LQW2BHNR15J03L B 163.5/27.5
L1052 6200010740 S.COL C2520C-R27G-A T 177.8/74.6
L1053 6200010740 S.COL C2520C-R27G-A T 173.8/73.5
L1054 6200010740 S.COL C2520C-R27G-A T 169.4/72.6
L1055 6140003960 COL LR-495
L1056 6200010730 S.COL C2520C-68NG-A T 171/83.8
L1058 6190001631 COL #E544EN-100021
L1060 6200010730 S.COL C2520C-68NG-A T 149.1/76.4
L1062 6200011450 S.COL C2520C-R39G-A T 145.1/81.4
L1063 6200010650 S.COL C2520C-R12G-A T 140.9/82.5
L1071 6200007780 S.COL LQW2BHNR12J03L B 164.9/79.2
L1072 6200007780 S.COL LQW2BHNR12J03L B 168/76.1
L1091 6200003950 S.COL HF50ACC 322513-T B 171/149
L1092 6200003950 S.COL HF50ACC 322513-T T 149.7/136.5
L1093 6200003950 S.COL HF50ACC 322513-T T 157/135.2
L1101 6140003920 COL LR-491
L1102 6200010650 S.COL C2520C-R12G-A T 176.9/117.9
L1103 6180001250 COL LAL 04NA 3R3K
L1104 6200010870 S.COL C2520C-R33G-A T 178.3/135.9
L1105 6140003910 COL LR-490
L1151 6140004640 COL LR-519
L1201 6200007780 S.COL LQW2BHNR12J03L B 119.3/17.4
L1208 6140003800 COL LR-439
L1209 6200001831 S.COL NLV32T-100J T 121.1/20.8
L1210 6140004440 COL LR-503
L1211 6200009690 S.COL LQH43CN101K03L T 115.7/34.6
L1212 6200001831 S.COL NLV32T-100J T 106.8/20.8
L1213 6140004440 COL LR-503
L1214 6200009690 S.COL LQH43CN101K03L T 105.9/34.8
L1216 6140003800 COL LR-439
L1217 6200007750 S.COL LQW2BHN56NJ03L T 147.9/63.7
L1218 6200007770 S.COL LQW2BHNR10J03L T 153.3/65.1
L1219 6200007790 S.COL LQW2BHNR15J03L T 153.2/68.4
L1220 6140000930 COL LR-116
L1221 6200003261 S.COL NLV32T-101J B 149.5/110.9
L1222 6150001770 COL LS-198
L1223 6200007750 S.COL LQW2BHN56NJ03L B 151.3/100.7
L1228 6200010870 S.COL C2520C-R33G-A T 158.7/71.3
L1229 6200003950 S.COL HF50ACC 322513-T B 164.7/115
L1301 6200008090 S.COL LQW2BHN68NJ03L T 157.1/111.9
L1302 6200008090 S.COL LQW2BHN68NJ03L T 156.4/115.5
L1303 6200008090 S.COL LQW2BHN68NJ03L T 153.4/117.5
L1304 6200010870 S.COL C2520C-R33G-A T 153.8/123
L1305 6200003001 S.COL NLV32T-R22J T 159.2/124.5
L1306 6200001831 S.COL NLV32T-100J B 152.7/118.6
L1307 6200003001 S.COL NLV32T-R22J T 153.3/112
L1351 6200001831 S.COL NLV32T-100J T 143/76.4
L1353 6200010740 S.COL C2520C-R27G-A T 141.6/67.5
L1354 6200001831 S.COL NLV32T-100J T 136.4/68
L1401 6150004280 COL LS-484B (C-14927)
L1402 6150004280 COL LS-484B (C-14927)
L1403 6150004280 COL LS-484B (C-14927)
To Next Page
