5 - 17
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[RXPLL-B UNIT]
L1404 6150004280 COL LS-484B (C-14927)
L1405 6200007770 S.COL LQW2BHNR10J03L B 112.5/111.4
L1406 6200007750 S.COL LQW2BHN56NJ03L B 116.6/111.4
L1407 6140003930 COL LR-492
L1408 6190001621 COL #E544EN-100028
L1409 6200003191 S.COL NLV32T-470J B 135.8/125.4
L1410 6150004280 COL LS-484B (C-14927)
L1411 6150004280 COL LS-484B (C-14927)
L1501 6200003520 S.COL ELJFB 102K-F T 142.1/145.1
L1652 6200002520 S.COL ELJNC R18K-F T 112.9/133.1
L1653 6200001831 S.COL NLV32T-100J B 105.4/124.6
L1654 6200001831 S.COL NLV32T-100J B 112.4/141.9
L1655 6200001831 S.COL NLV32T-100J B 124.7/139.8
L1701 6200001831 S.COL NLV32T-100J T 167/160
L1702 6200003950 S.COL HF50ACC 322513-T T 175.6/169.8
L1703 6200003950 S.COL HF50ACC 322513-T T 172.6/169.8
L1704 6200003950 S.COL HF50ACC 322513-T T 169.6/169.8
L1705 6200003950 S.COL HF50ACC 322513-T T 165.5/169.8
L1803 6200003950 S.COL HF50ACC 322513-T B 132/54.8
L1804 6200003950 S.COL HF50ACC 322513-T B 118/154.8
L1805 6200003950 S.COL HF50ACC 322513-T B 155.2/132
L1807 6200003950 S.COL HF50ACC 322513-T B 118/151.3
L1808 6200003950 S.COL HF50ACC 322513-T B 141.3/162
L1809 6200003950 S.COL HF50ACC 322513-T B 149.5/115.6
R1 7030005871 S.RES ERA3YKD 104V (100 k) T 32.5/19.2
R2 7030005321 S.RES ERA3YED 103V (10 k) T 31.2/19.2
R3 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 16.9/23.5
R4 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 16.9/24.8
R5 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 13.3/31.3
R6 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 13.3/30
R7 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 26.7/12.9
R8 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) B 28.2/14.6
R9 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 27.5/10.6
R10 7030003360 S.RES ERJ3GEYJ 221 V (220) T 19/16
R11 7030003360 S.RES ERJ3GEYJ 221 V (220) T 20.3/16
R12 7030003360 S.RES ERJ3GEYJ 221 V (220) T 22.4/16
R13 7030003360 S.RES ERJ3GEYJ 221 V (220) T 23.7/16
R14 7030003360 S.RES ERJ3GEYJ 221 V (220) T 25/16
R15 7030003360 S.RES ERJ3GEYJ 221 V (220) T 26.4/16.2
R16 7030003360 S.RES ERJ3GEYJ 221 V (220) T 32.5/15.4
R17 7030003360 S.RES ERJ3GEYJ 221 V (220) T 33.8/15.4
R30 7030003240 S.RES ERJ3GEYJ 220 V (22) T 21.7/113.7
R31 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 20.4/111.1
R32 7030003320 S.RES ERJ3GEYJ 101 V (100) T 23/113.7
R33 7030003340 S.RES ERJ3GEYJ 151 V (150) T 19.1/115
R51 7030011030 S.RES ERJ1TYJ 270U (27) T 66.3/13.9
R61 7030011030 S.RES ERJ1TYJ 270U (27) T 45.1/13.9
R101 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 34.1/101.5
R102 7030003860 S.RES ERJ3GE JPW V B 35.6/88.6
R103 7030007230 S.RES ERA3YED 102V (1 k) T 25.1/100.3
R104 7030007230 S.RES ERA3YED 102V (1 k) T 26.4/100.3
R105 7030007230 S.RES ERA3YED 102V (1 k) T 27.8/100.3
R106 7030003360 S.RES ERJ3GEYJ 221 V (220) T 29.1/100.3
R107 7030003320 S.RES ERJ3GEYJ 101 V (100) T 38/101.5
R108 7030007230 S.RES ERA3YED 102V (1 k) T 28.9/79
R109 7030007230 S.RES ERA3YED 102V (1 k) T 41.9/84.5
R110 7030007220 S.RES ERA3YED 202V (2 k) T 14.6/100.5
R111 7030007220 S.RES ERA3YED 202V (2 k) T 17.2/100.5
R112 7030007220 S.RES ERA3YED 202V (2 k) T 17.2/99.2
R113 7030007220 S.RES ERA3YED 202V (2 k) T 17.2/97.9
R114 7030007220 S.RES ERA3YED 202V (2 k) T 17.2/96.6
R115 7030007220 S.RES ERA3YED 202V (2 k) T 17.2/95.2
R116 7030007220 S.RES ERA3YED 202V (2 k) T 17.2/93.9
R117 7030007220 S.RES ERA3YED 202V (2 k) T 17.2/92.6
R118 7030007200 S.RES ERA3YEB 202V (2 k) T 17.2/91.3
R119 7030007200 S.RES ERA3YEB 202V (2 k) T 17.2/89.6
R120 7030007200 S.RES ERA3YEB 202V (2 k) T 17.2/87
R121 7030007200 S.RES ERA3YEB 202V (2 k) T 17.2/84.4
R122 7030007200 S.RES ERA3YEB 202V (2 k) T 17.2/81.8
R123 7030007230 S.RES ERA3YED 102V (1 k) T 14.6/99.2
R124 7030007230 S.RES ERA3YED 102V (1 k) T 14.6/97.9
R125 7030007230 S.RES ERA3YED 102V (1 k) T 14.6/96.6
R126 7030007230 S.RES ERA3YED 102V (1 k) T 14.6/95.2
R127 7030007230 S.RES ERA3YED 102V (1 k) T 14.6/93.9
R128 7030007230 S.RES ERA3YED 102V (1 k) T 14.6/92.6
R129 7030007210 S.RES ERA3YEB 102V (1 k) T 14.6/91.3
R130 7030007210 S.RES ERA3YEB 102V (1 k) T 14.6/89.6
R131 7030007210 S.RES ERA3YEB 102V (1 k) T 14.6/88.3
R132 7030007210 S.RES ERA3YEB 102V (1 k) T 14.6/87
R133 7030007210 S.RES ERA3YEB 102V (1 k) T 14.6/85.7
R134 7030009861 S.RES ERA3YED 471V (470) T 14.6/84.4
R135 7030003860 S.RES ERJ3GE JPW V T 30.4/75.8
R136 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 33/77.1
R137 7030003200 S.RES ERJ3GEYJ 100 V (10) T 35.5/75.8
R138 7030003860 S.RES ERJ3GE JPW V T 16.8/78.6
R139 7030003860 S.RES ERJ3GE JPW V T 17.6/75.8
R150 7030003330 S.RES ERJ3GEYJ 121 V (120) B 37.8/86.2
R151 7030003220 S.RES ERJ3GEYJ 150 V (15) B 38.6/88.1
R152 7030005871 S.RES ERA3YKD 104V (100 k) B 36.2/82.5
R153 7030005321 S.RES ERA3YED 103V (10 k) T 19.2/62.7
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[RXPLL-B UNIT]
R154 7030003320 S.RES ERJ3GEYJ 101 V (100) B 26.3/54.1
R155 7030003350 S.RES ERJ3GEYJ 181 V (180) B 23/54.1
R156 7030005871 S.RES ERA3YKD 104V (100 k) T 24.6/53.1
R157 7030005871 S.RES ERA3YKD 104V (100 k) T 26.9/58
R158 7030003340 S.RES ERJ3GEYJ 151 V (150) T 30/57.3
R159 7030003320 S.RES ERJ3GEYJ 101 V (100) B 33.6/61.4
R160 7030003360 S.RES ERJ3GEYJ 221 V (220) B 33.6/59.6
R161 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 33.6/54.8
R163 7030003220 S.RES ERJ3GEYJ 150 V (15) B 30.2/56.6
R164 7030003310 S.RES ERJ3GEYJ 820 V (82) B 34.1/70.4
R165 7030003320 S.RES ERJ3GEYJ 101 V (100) B 30.8/70.4
R166 7030003320 S.RES ERJ3GEYJ 101 V (100) B 30.8/72.2
R167 7030003240 S.RES ERJ3GEYJ 220 V (22) B 37.4/75.8
R168 7030003360 S.RES ERJ3GEYJ 221 V (220) B 34.1/75.8
R169 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 30.8/75.8
R202 7030007230 S.RES ERA3YED 102V (1 k) T 22.2/39.7
R203 7030007230 S.RES ERA3YED 102V (1 k) T 22.2/38.4
R204 7030003360 S.RES ERJ3GEYJ 221 V (220) T 22.2/37.1
R205 7030005321 S.RES ERA3YED 103V (10 k) T 27.4/34
R206 7030003220 S.RES ERJ3GEYJ 150 V (15) T 31.1/45.7
R210 7030005351 S.RES ERA3YED 182V (1.8 k) T 35.6/37.5
R217 7030009651 S.RES ERA3YHD 820V (82) B 40.4/42.8
R219 7030009691 S.RES ERA3YED 101V (100) B 40/35.7
R220 7030005871 S.RES ERA3YKD 104V (100 k) T 73.2/37.6
R221 7030005871 S.RES ERA3YKD 104V (100 k) T 72.3/30.9
R222 7030003360 S.RES ERJ3GEYJ 221 V (220) T 81.4/38.3
R223 7030007230 S.RES ERA3YED 102V (1 k) T 81.9/31.9
R224 7030003320 S.RES ERJ3GEYJ 101 V (100) T 73.2/40.2
R230 7030005871 S.RES ERA3YKD 104V (100 k) T 73.2/50.1
R231 7030005871 S.RES ERA3YKD 104V (100 k) T 72.3/43.3
R232 7030003360 S.RES ERJ3GEYJ 221 V (220) T 81.4/50.8
R233 7030007230 S.RES ERA3YED 102V (1 k) T 81.9/44.4
R234 7030003320 S.RES ERJ3GEYJ 101 V (100) T 73.2/52.7
R240 7030005871 S.RES ERA3YKD 104V (100 k) T 73.2/62.6
R241 7030005871 S.RES ERA3YKD 104V (100 k) T 72.3/55.8
R242 7030003360 S.RES ERJ3GEYJ 221 V (220) T 81.4/63.3
R243 7030007230 S.RES ERA3YED 102V (1 k) T 81.9/56.9
R244 7030003320 S.RES ERJ3GEYJ 101 V (100) T 73.2/65.2
R250 7030005871 S.RES ERA3YKD 104V (100 k) T 73.2/75.1
R251 7030005871 S.RES ERA3YKD 104V (100 k) T 72.3/68.4
R252 7030003360 S.RES ERJ3GEYJ 221 V (220) T 81.4/75.8
R253 7030007230 S.RES ERA3YED 102V (1 k) T 81.9/69.4
R254 7030003320 S.RES ERJ3GEYJ 101 V (100) T 73.2/77.7
R260 7030005871 S.RES ERA3YKD 104V (100 k) T 73.2/87.6
R261 7030005871 S.RES ERA3YKD 104V (100 k) T 72.3/80.9
R262 7030003360 S.RES ERJ3GEYJ 221 V (220) T 81.4/88.3
R263 7030007230 S.RES ERA3YED 102V (1 k) T 81.9/81.9
R264 7030003320 S.RES ERJ3GEYJ 101 V (100) T 73.2/90.2
R270 7030005871 S.RES ERA3YKD 104V (100 k) T 73.2/99.5
R271 7030005871 S.RES ERA3YKD 104V (100 k) T 72.3/92.8
R272 7030003360 S.RES ERJ3GEYJ 221 V (220) T 81.4/100.8
R273 7030007230 S.RES ERA3YED 102V (1 k) T 81.9/93.9
R274 7030003320 S.RES ERJ3GEYJ 101 V (100) T 73.2/102.1
R301 7030003200 S.RES ERJ3GEYJ 100 V (10) T 86.5/30.6
R302 7030007230 S.RES ERA3YED 102V (1 k) T 86.5/29.3
R303 7030003360 S.RES ERJ3GEYJ 221 V (220) T 92.1/28
R304 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) T 94/30.1
R305 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) T 95.3/30.1
R306 7030003360 S.RES ERJ3GEYJ 221 V (220) T 94.7/32.2
R307 7030009841 S.RES ERA3YHD 330V (33) T 92.1/32.2
R308 7030009851 S.RES ERA3YED 271V (270) B 92.6/43.4
R309 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 89.1/47
R310 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 92.6/47
R311 7030003350 S.RES ERJ3GEYJ 181 V (180) B 89.1/45.2
R312 7030003360 S.RES ERJ3GEYJ 221 V (220) B 92.4/27.8
R313 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) B 91.1/23.1
R314 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) B 88.3/23.1
R315 7030003360 S.RES ERJ3GEYJ 221 V (220) B 87.5/25.1
R316 7030003280 S.RES ERJ3GEYJ 470 V (47) B 78.3/26.1
R317 7030006220 S.RES ERJ12YJ470U (47) B 90/31.4
R318 7030009841 S.RES ERA3YHD 330V (33) B 92.6/41.6
R341 7030007230 S.RES ERA3YED 102V (1 k) T 92.1/40.1
R342 7030005321 S.RES ERA3YED 103V (10 k) T 86.5/32.2
R343 7030007230 S.RES ERA3YED 102V (1 k) T 89.3/34.8
R351 7030003200 S.RES ERJ3GEYJ 100 V (10) B 89.1/52.4
R352 7030010980 S.RES ERA3YHD 470V (47) T 89.3/55.8
R353 7030009591 S.RES ERA3YED 472V (4.7 k) T 89.3/54.5
R354 7030009591 S.RES ERA3YED 472V (4.7 k) T 89.3/50.4
R355 7030009591 S.RES ERA3YED 472V (4.7 k) T 89.3/53.2
R356 7030003320 S.RES ERJ3GEYJ 101 V (100) T 89.3/57.1
R357 7310005050 S.TRI RH03ADCS3X (4.7 k) T 93.6/52.7
R358 7030010980 S.RES ERA3YHD 470V (47) T 94.9/56.4
R359 7030003320 S.RES ERJ3GEYJ 101 V (100) T 94.9/59
R360 7030003320 S.RES ERJ3GEYJ 101 V (100) B 92.6/63.9
R361 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) B 89.2/62.1
R362 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) B 92.6/60.3
R363 7030003320 S.RES ERJ3GEYJ 101 V (100) B 92.6/65.7
R364 7030003410 S.RES ERJ3GEYJ 561 V (560) T 94.9/82.9
R365 7030007860 S.RES ERJ3GEYJ 8R2V (8.2) T 92/83.4
R366 7030003410 S.RES ERJ3GEYJ 561 V (560) T 94.9/84.2
R368 7030005321 S.RES ERA3YED 103V (10 k) T 86.1/59.6
R369 7030008240 S.RES ERJ12YJ0R00U B 95.3/57.1
