Icom IC-A25C User Manual

8
MEMORY OPERATION
8-3
D Memory channel name
([MENU] > Manage Memory > Edit Memory >
(Select a group) > (Select a channel) > Name)
Edit a memory channel name.
Usable characters are displayed on the screen.
L Push [DOWN] to select and enter the characters, as
shown below.
(space) ~ } | { ` _ ^ ] \ [ @ ? > = < ; : / . - , + * ) ( ' & %
$ # " !
L Push [RIGHT] or [LEFT] to move the cursor.
Editing memory channels (Continued)
D Type
([MENU] > Manage Memory > Edit Memory >
(Select a group) > (Select a channel) > Type)
Select the type that indicates the type of equipment,
as shown below.
Item Type
TWR Tower
GND Ground
ATS Automatic Terminal Information Service
ATF AerodromeTrafcFrequency
APP Approach
ARR Arrival
AWS Automated Weather Observing System
CLR Clearance
CTF CommonTrafcAdvisoryFrequency
DEP Departure
FSS Flight Service Station
INT Intersection
RFS Remote Flight Service Station
UNI Unicom
MF Mandatory Frequency
VOR VOR
OTH Other
WPT Waypoint
U-1/U-2 You can edit these type names on the
“User Type 1” or “User Type 2”screen.
([MENU] >Manage Memory > User type >
User Type 1/User Type 2) (p. 8-5)

Icom IC-A25C Specifications

General

Purpose	Aviation Service (Air Band)
Operating frequency	118.000 – 136.992 MHz
Display type	LCD
Display diagonal	2.3 \
Battery type	BP-288
Battery life (max)	10.5 h
Battery low indication	Yes
Number of batteries supported	1
Product color	Black
Operating temperature (T-T)	-10 - 60 °C
Number of batteries included	1 pc(s)
Antenna connector type	FA-B02AR

Weight and Dimensions

Depth	31.8 mm
Width	58.9 mm
Height	148.4 mm
Weight	384 g
