Icom IC-M220 Service Manual

2-2
• LOGIC UNIT (TOP VIEW)
• LOGIC UNIT (BOTTOM VIEW)
3.3 V REGULATOR
(IC4)
7.9872 MHz
SYSTEM CLOCK
(X1)
LCD
(DS1)
EEPROM
(IC9)
NMEA BUFFER
(IC5)
J5
J4
J2
J1
CPU
(IC1)
DSC SWITCH
(IC3)
GPS RECEIVER IC
*
(IC201)
GPS- ANT BOARD
*
MIC-JACK BOARD
*
Available only with the IC-M220G.
LOGIC UNIT
