Icom IC-M73 - Section 6 Parts List

Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
6-1
SECTION 6
.
PARTS LIST
IC170 1110008140 S.IC GT3136 <SEI> B 51.2/33.0
IC190 1110007550 S.IC R2A20178NP B 51.4/11.6
IC200 1110006350 S.IC LM2902PWR B 29.7/33.6
IC220 1180003830 S.REG NJU7772F05-TE1-#ZZZB B 63.3/6.6
IC260 1130009981 S.IC TC7W53FK(TE85LF) B 16.6/4.9
IC280 1110007850 S.IC TA7368PL-R10-R <SLVJ> B 31.8/8.0
IC340 1130015560 S.IC S-24C64CI-T8T1U3 B 66.7/37.8
IC341 1110007620 S.IC NJU7704F3-42A-TE1-#ZZZB B 73.9/34.8
IC360 1140016550 S.IC UPD780338GC-519-9EB-A B 74.3/12.7
IC364 1130016110 S.IC TC7WH14FK(TE85LF) B 78.4/36.5
IC401 1110002420 S.IC NJM2073M-TE1-#ZZZB B 9.5/3.8
IC430 1130011770 S.IC CD4066BPWR B 17.8/36.9
IC431 1110006380 S.IC LM2904PWR B 15.9/31.3
IC432 1110006380 S.IC LM2904PWR B 34.3/20.1
IC500 1190003590 S.IC LC703200AW-8C01-H [USA-10] B 21.4/16.4
1190003590 S.IC LC703200AW-8C01-H [EXP-10]
1190003590 S.IC LC703200AW-8C01-H [EUR-11]
1190003590 S.IC LC703200AW-8C01-H [EUR-10]
1190003590 S.IC LC703200AW-8C01-H [UK-10]
1190003590 S.IC LC703200AW-8C01-H [FRG-10]
1190003590 S.IC LC703200AW-8C01-H [HOL-10]
1190003590 S.IC LC703200AW-8C01-H [AUS-10]
IC501 1130016740 S.IC LE25U40CMC-AH [USA-10] B 16.3/25.7
1130016740 S.IC LE25U40CMC-AH [EXP-10]
1130016740 S.IC LE25U40CMC-AH [EUR-11]
1130016740 S.IC LE25U40CMC-AH [EUR-10]
1130016740 S.IC LE25U40CMC-AH [UK-10]
1130016740 S.IC LE25U40CMC-AH [FRG-10]
1130016740 S.IC LE25U40CMC-AH [HOL-10]
1130016740 S.IC LE25U40CMC-AH [AUS-10]
IC502 1180003980 S.REG XC6221A332MR-G [USA-10] B 23.5/27.0
1180003980 S.REG XC6221A332MR-G [EXP-10]
1180003980 S.REG XC6221A332MR-G [EUR-11]
1180003980 S.REG XC6221A332MR-G [EUR-10]
1180003980 S.REG XC6221A332MR-G [UK-10]
1180003980 S.REG XC6221A332MR-G [FRG-10]
1180003980 S.REG XC6221A332MR-G [HOL-10]
1180003980 S.REG XC6221A332MR-G [AUS-10]
IC503 1180004200 S.REG XC6221A152MR-G [USA-10] B 27.9/27.0
1180004200 S.REG XC6221A152MR-G [EXP-10]
1180004200 S.REG XC6221A152MR-G [EUR-11]
1180004200 S.REG XC6221A152MR-G [EUR-10]
1180004200 S.REG XC6221A152MR-G [UK-10]
1180004200 S.REG XC6221A152MR-G [FRG-10]
1180004200 S.REG XC6221A152MR-G [HOL-10]
1180004200 S.REG XC6221A152MR-G [AUS-10]
IC504 1130011741 S.IC TC7W66FK(TE85LF) [USA-10] B 32.2/26.2
1130011741 S.IC TC7W66FK(TE85LF) [EXP-10]
1130011741 S.IC TC7W66FK(TE85LF) [EUR-11]
1130011741 S.IC TC7W66FK(TE85LF) [EUR-10]
1130011741 S.IC TC7W66FK(TE85LF) [UK-10]
1130011741 S.IC TC7W66FK(TE85LF) [FRG-10]
1130011741 S.IC TC7W66FK(TE85LF) [HOL-10]
1130011741 S.IC TC7W66FK(TE85LF) [AUS-10]
Q221 1510001151 S.TRA L2SA1576AST1G <SLVJ> B 51.2/17.4
Q223 1590004070 S.TRA LDTC144EET1G <SLVJ> B 55.3/15.7
Q224 1590003800 S.TRA KTC811U-GR-RTK/P B 58.0/14.9
Q225 1520000840 S.TRA KTA1664Y-RTF/P B 61.4/11.9
Q230 1550000090 S.FET RSQ035P03TR B 59.4/6.4
Q231 1590003800 S.TRA KTC811U-GR-RTK/P B 55.4/6.4
Q240 1590004070 S.TRA LDTC144EET1G <SLVJ> B 83.6/32.2
Q250 1590004070 S.TRA LDTC144EET1G <SLVJ> B 10.7/40.7
Q350 1530004140 S.TRA L2SC4081RT1G <SLVJ> B 82.2/29.6
Q361 1510001151 S.TRA L2SA1576AST1G <SLVJ> B 78.5/32.8
Q401 1590004070 S.TRA LDTC144EET1G <SLVJ> B 52.9/3.9
Q430 1590004310 S.TRA LDTA114EET1G <SLVJ> B 11.6/36.1
Q470 1590004070 S.TRA LDTC144EET1G <SLVJ> B 18.7/2.7
Q500 1590004070 S.TRA LDTC144EET1G <SLVJ> B 84.2/7.2
Q542 1590004070 S.TRA LDTC144EET1G <SLVJ> B 68.5/23.6
Q550 1590004070 S.TRA LDTC144EET1G <SLVJ>
[USA-10] B 67.1/20.8
1590004070 S.TRA LDTC144EET1G <SLVJ>
[EXP-10]
1590004070 S.TRA LDTC144EET1G <SLVJ>
[EUR-11]
1590004070 S.TRA LDTC144EET1G <SLVJ>
[EUR-10]
1590004070 S.TRA LDTC144EET1G <SLVJ> [UK-10]
1590004070 S.TRA LDTC144EET1G <SLVJ>
[FRG-10]
1590004070 S.TRA LDTC144EET1G <SLVJ>
[HOL-10]
1590004070 S.TRA LDTC144EET1G <SLVJ>
[AUS-10]
Q551 1590004070 S.TRA LDTC144EET1G <SLVJ> B 69.9/36.3
Q552 1560001360 S.FET 2SK3019 TL [USA-10] B 72.1/28.1
1560001360 S.FET 2SK3019 TL [EXP-10]
1560001360 S.FET 2SK3019 TL [EUR-11]
1560001360 S.FET 2SK3019 TL [EUR-10]
1560001360 S.FET 2SK3019 TL [UK-10]
1560001360 S.FET 2SK3019 TL [FRG-10]
1560001360 S.FET 2SK3019 TL [HOL-10]
1560001360 S.FET 2SK3019 TL [AUS-10]
Q553 1560001360 S.FET 2SK3019 TL [USA-10] B 68.4/26.1
1560001360 S.FET 2SK3019 TL [EXP-10]
1560001360 S.FET 2SK3019 TL [EUR-11]
1560001360 S.FET 2SK3019 TL [EUR-10]
1560001360 S.FET 2SK3019 TL [UK-10]
1560001360 S.FET 2SK3019 TL [FRG-10]
1560001360 S.FET 2SK3019 TL [HOL-10]
1560001360 S.FET 2SK3019 TL [AUS-10]
REF PARTS
DESCRIPTION M.
H/V
NO. NO. LOCATION
[MAIN UNIT]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
D350 1750001810 S.DIO L1SS400T1G <SLVJ> B 80.3/29.4
D430 1750002020 S.DIO DA2S10100L B 21.3/30.4
D431 1750001850 S.DIO LDAN222T1G <SLVJ> B 70.6/34.0
X170 6070000310 S.DIS JTBM450CX70 <JJE> B 53.3/23.5
X480 6050012460 S.XTA CR-834(SMD-49/7.9872 MHz)
<JJE> B 79.2/25.6
X481 6060000880 S.CER CSTCE8M19G55 [USA-10] B 29.5/21.8
6060000880 S.CER CSTCE8M19G55 [EXP-10]
6060000880 S.CER CSTCE8M19G55 [EUR-11]
6060000880 S.CER CSTCE8M19G55 [EUR-10]
6060000880 S.CER CSTCE8M19G55 [UK-10]
6060000880 S.CER CSTCE8M19G55 [FRG-10]
6060000880 S.CER CSTCE8M19G55 [HOL-10]
6060000880 S.CER CSTCE8M19G55 [AUS-10]
L10 6200002861 S.COI NLV25T-4R7J [USA-10] B 13.5/9.5
6200002861 S.COI NLV25T-4R7J [EXP-10]
6200002861 S.COI NLV25T-4R7J [EUR-11]
6200002861 S.COI NLV25T-4R7J [EUR-10]
6200002861 S.COI NLV25T-4R7J [UK-10]
6200002861 S.COI NLV25T-4R7J [FRG-10]
6200002861 S.COI NLV25T-4R7J [HOL-10]
6200002861 S.COI NLV25T-4R7J [AUS-10]
L11 6200002861 S.COI NLV25T-4R7J [USA-10] B 11.0/9.5
6200002861 S.COI NLV25T-4R7J [EXP-10]
6200002861 S.COI NLV25T-4R7J [EUR-11]
6200002861 S.COI NLV25T-4R7J [EUR-10]
6200002861 S.COI NLV25T-4R7J [UK-10]
6200002861 S.COI NLV25T-4R7J [FRG-10]
6200002861 S.COI NLV25T-4R7J [HOL-10]
6200002861 S.COI NLV25T-4R7J [AUS-10]
L12 6200002861 S.COI NLV25T-4R7J [USA-10] B 16.0/9.5
6200002861 S.COI NLV25T-4R7J [EXP-10]
6200002861 S.COI NLV25T-4R7J [EUR-11]
6200002861 S.COI NLV25T-4R7J [EUR-10]
6200002861 S.COI NLV25T-4R7J [UK-10]
6200002861 S.COI NLV25T-4R7J [FRG-10]
6200002861 S.COI NLV25T-4R7J [HOL-10]
6200002861 S.COI NLV25T-4R7J [AUS-10]
R160 7030005050 S.RES ERJ2GEJ 103 X (10K) B 49.7/15.0
R170 7030009280 S.RES ERJ2GEJ 391 X B 51.3/28.0
R171 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 52.9/28.0
R172 7030005000 S.RES ERJ2GEJ 471 X (470) B 54.1/28.5
R173 7030005050 S.RES ERJ2GEJ 103 X (10K) B 50.4/37.0
R174 7030005230 S.RES ERJ2GEJ 334 X (330K) B 53.7/37.0
R175 7030008290 S.RES ERJ2GEJ 183 X (18K) B 54.5/38.8
R176 7030005120 S.RES ERJ2GEJ 102 X (1K) B 55.8/38.0
R192 7030009280 S.RES ERJ2GEJ 391 X B 51.2/7.2
R193 7030005000 S.RES ERJ2GEJ 471 X (470) B 54.8/12.9
R194 7030005090 S.RES ERJ2GEJ 104 X (100K) B 50.3/7.2
R201 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 34.4/31.9
R202 7030005090 S.RES ERJ2GEJ 104 X (100K) B 34.5/33.7
R203 7030006610 S.RES ERJ2GEJ 394 X (390K) B 34.4/31.0
R204 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 31.0/30.3
R206 7030008290 S.RES ERJ2GEJ 183 X (18K) B 32.6/29.3
R207 7030005600 S.RES ERJ2GEJ 273 X (27K) B 32.6/30.5
R212 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 25.0/32.6
R213 7030005310 S.RES ERJ2GEJ 124 X (120K) B 23.8/31.8
R214 7030007340 S.RES ERJ2GEJ 153 X (15K) B 22.6/31.3
R222 7030005240 S.RES ERJ2GEJ 473 X (47K) B 49.4/17.5
R223 7030005050 S.RES ERJ2GEJ 103 X (10K) B 52.9/16.7
R226 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 56.2/14.4
R227 7030005050 S.RES ERJ2GEJ 103 X (10K) B 62.5/14.9
R228 7030005220 S.RES ERJ2GEJ 223 X (22K) B 57.8/16.7
R230 7030005720 S.RES ERJ2GEJ 563 X (56K) B 57.1/4.4
R231 7030005160 S.RES ERJ2GEJ 105 X (1M) B 56.2/4.4
R232 7030005120 S.RES ERJ2GEJ 102 X (1K) B 54.4/4.4
R233 7030005220 S.RES ERJ2GEJ 223 X (22K) B 56.0/8.2
R234 7030005060 S.RES ERJ2GEJ 333 X (33K) B 53.4/5.9
R235 7030010010 S.RES ERJ2RKF 334 X (330K) B 59.3/9.5
R236 7030010020 S.RES ERJ2RKF 1503X (150K) B 58.2/10.4
R240 7030008280 S.RES ERJ2GEJ 271 X (270) B 64.8/3.8
R241 7030005010 S.RES ERJ2GEJ 681 X (680) B 71.0/38.7
R243 7030008280 S.RES ERJ2GEJ 271 X (270) B 64.4/39.2
R244 7030005010 S.RES ERJ2GEJ 681 X (680) B 69.8/39.1
R250 7030005050 S.RES ERJ2GEJ 103 X (10K) B 12.7/38.0
R251 7030005000 S.RES ERJ2GEJ 471 X (470) B 14.5/38.7
R252 7030005060 S.RES ERJ2GEJ 333 X (33K) B 9.6/38.1
R253 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 24.2/34.6
R255 7030005170 S.RES ERJ2GEJ 474 X (470K) B 25.4/35.3
R256 7030008290 S.RES ERJ2GEJ 183 X (18K) B 22.6/33.7
R257 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 24.5/36.0
R258 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 23.3/35.5
R260 7030006610 S.RES ERJ2GEJ 394 X (390K) B 11.1/34.6
R261 7030005240 S.RES ERJ2GEJ 473 X (47K) B 11.7/33.7
R262 7030005600 S.RES ERJ2GEJ 273 X (27K) B 9.5/33.7
R263 7030005090 S.RES ERJ2GEJ 104 X (100K) B 35.5/27.7
R264 7030005090 S.RES ERJ2GEJ 104 X (100K) B 21.1/38.3
R265 7030005090 S.RES ERJ2GEJ 104 X (100K) B 14.3/34.6
R271 7030005090 S.RES ERJ2GEJ 104 X (100K) B 35.4/14.2
R272 7030005310 S.RES ERJ2GEJ 124 X (120K) B 35.7/15.1
R273 7030005240 S.RES ERJ2GEJ 473 X (47K) B 34.5/15.4
R274 7030005700 S.RES ERJ2GEJ 274 X (270K) B 32.5/14.2
