Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PART
NO.
DESCRIPTION M.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M.
H/V
LOCATION
6-1
SECTION 6 PARTS LIST
[MAIN UNIT] [MAIN UNIT]
Q5041 1590004690 S.TRA LDTC143ZET1G T 158.5/50.4
Q5042 1530004140 S.TRA L2SC4081RT1G T 155.8/51.1
Q5081 1510000502 S.TRA 2SA1162-GRLF T 212.0/44.5
Q5082 1530004140 S.TRA L2SC4081RT1G T 211.9/41.5
Q5421 1530004590 S.TRA BFR193F H6327 T 118.8/48.2
Q5422 1510001270 S.TRA 2SAR502UBTL T 120.1/50.7
Q5481 1530004590 S.TRA BFR193F H6327 T 124.7/48.2
Q5482 1510001270 S.TRA 2SAR502UBTL T 126.0/50.7
Q5581 1530004140 S.TRA L2SC4081RT1G T 99.3/58.5
Q5582 1530004140 S.TRA L2SC4081RT1G T 109.7/57.2
Q5651 1590004690 S.TRA LDTC143ZET1G T 54.5/18.8
Q5661 1590004690 S.TRA LDTC143ZET1G T 181.5/18.7
Q5681 1590004690 S.TRA LDTC143ZET1G T 54.5/12.1
Q5901 1590005220 S.TRA LDTA114YET1G T 209.4/81.0
Q5902 1550000610 S.FET RU1L002SNTL T 209.6/78.7
Q5911 1530004140 S.TRA L2SC4081RT1G T 209.5/83.4
Q5931 1590005220 S.TRA LDTA114YET1G T 199.2/82.8
Q5932 1590004690 S.TRA LDTC143ZET1G T 199.6/76.8
Q5981 1510001270 S.TRA 2SAR502UBTL T 203.5/79.6
D4021 1750001810 S.DIO L1SS400T1G T 109.7/101.4
D4023 1750001820 S.DIO LRB706F-40T1G T 119.8/100.1
D4024 1750001820 S.DIO LRB706F-40T1G T 119.8/102.6
D4035 1750001810 S.DIO L1SS400T1G T 103.5/102.1
D4071 1750001820 S.DIO LRB706F-40T1G T 187.1/107.2
D4072 1750001820 S.DIO LRB706F-40T1G T 185.5/100.9
D4074 1750001820 S.DIO LRB706F-40T1G T 137.7/104.8
D4101 1750001820 S.DIO LRB706F-40T1G T 191.7/15.6
D4102 1750001820 S.DIO LRB706F-40T1G T 173.7/100.3
D4103 1750001820 S.DIO LRB706F-40T1G T 171.2/100.3
D4141 1750001810 S.DIO L1SS400T1G T 146.9/13.0
D4142 1750001810 S.DIO L1SS400T1G T 171.6/9.2
D4383 1750002110 S.DIO LRB551V-30T1G T 114.5/4.5
D4401 1790001622 S.DIO 1SV308L3F T 8.7/82.7
D4421 1790001622 S.DIO 1SV308L3F T 10.4/69.0
D4434 1750003040 S.DIO L709CEAR T 5.4/59.9
D4435 1750003040 S.DIO L709CEAR T 5.4/57.2
D4451 1790001622 S.DIO 1SV308L3F T 17.4/79.9
D4452 1790001622 S.DIO 1SV308L3F T 17.4/64.1
D4471 1790001622 S.DIO 1SV308L3F T 22.0/85.6
D4472 1790001622 S.DIO 1SV308L3F T 22.0/64.1
D4491 1790001622 S.DIO 1SV308L3F T 26.6/85.6
D4492 1790001622 S.DIO 1SV308L3F T 26.7/64.1
D4511 1790001622 S.DIO 1SV308L3F T 32.7/85.6
D4512 1790001622 S.DIO 1SV308L3F T 32.7/64.1
D4531 1790001622 S.DIO 1SV308L3F T 38.8/85.6
D4532 1790001622 S.DIO 1SV308L3F T 38.8/64.1
D4551 1790001622 S.DIO 1SV308L3F T 44.9/85.6
D4552 1790001622 S.DIO 1SV308L3F T 44.9/64.1
D4571 1790001622 S.DIO 1SV308L3F T 49.4/85.6
D4572 1790001622 S.DIO 1SV308L3F T 49.4/64.1
D4591 1790001622 S.DIO 1SV308L3F T 53.9/85.6
D4592 1790001622 S.DIO 1SV308L3F T 54.0/63.2
D4611 1790001622 S.DIO 1SV308L3F T 59.2/85.6
D4612 1790001622 S.DIO 1SV308L3F T 59.3/63.2
D4631 1790001622 S.DIO 1SV308L3F T 69.6/60.0
D4632 1790001622 S.DIO 1SV308L3F T 84.9/57.8
D4641 1790001622 S.DIO 1SV308L3F T 69.6/65.1
D4642 1790001622 S.DIO 1SV308L3F T 84.9/68.1
D4643 1750001810 S.DIO L1SS400T1G T 102.5/54.6
D4661 1790001622 S.DIO 1SV308L3F T 68.1/60.0
D4662 1750003070 S.DIO BAP70Q T 69.2/54.2
D4663 1750003070 S.DIO BAP70Q T 78.2/52.6
D4664 1750003070 S.DIO BAP70Q T 87.9/52.6
D4665 1750001810 S.DIO L1SS400T1G T 102.5/51.4
D4666 1790001622 S.DIO 1SV308L3F T 92.0/52.2
D4701 1750003040 S.DIO L709CEAR T 10.9/106.8
D4702 1750003040 S.DIO L709CEAR T 13.6/106.8
D4703 1750001820 S.DIO LRB706F-40T1G T 16.6/108.5
D4704 1750001810 S.DIO L1SS400T1G T 12.3/101.6
D4731 1790001622 S.DIO 1SV308L3F T 18.5/91.7
D4732 1790001622 S.DIO 1SV308L3F T 20.4/115.4
D4751 1790001622 S.DIO 1SV308L3F T 25.9/91.7
D4752 1790001622 S.DIO 1SV308L3F T 26.5/114.8
D4771 1790001622 S.DIO 1SV308L3F T 33.5/91.7
D4772 1790001622 S.DIO 1SV308L3F T 33.6/113.5
D4791 1790001622 S.DIO 1SV308L3F T 41.0/91.7
D4792 1790001622 S.DIO 1SV308L3F T 41.0/115.9
D4811 1790001622 S.DIO 1SV308L3F T 49.2/90.5
D4812 1790001622 S.DIO 1SV308L3F T 49.2/115.2
D4841 1790001622 S.DIO 1SV308L3F T 57.0/90.5
D4842 1790001622 S.DIO 1SV308L3F T 56.8/115.2
D4871 1790001622 S.DIO 1SV308L3F T 71.6/110.2
D4872 1790001622 S.DIO 1SV308L3F T 71.6/97.6
D4881 1790001622 S.DIO 1SV308L3F T 77.0/110.2
D4882 1750001810 S.DIO L1SS400T1G T 115.9/92.8
D4883 1790001622 S.DIO 1SV308L3F T 81.5/97.6
D5071 1750003410 S.ZEN RCLAMP7524T.TNT T 197.7/14.8
D5081 1750001810 S.DIO L1SS400T1G T 215.8/42.8
D5161 1750003070 S.DIO BAP70Q T 88.1/71.7
D5221 1750003070 S.DIO BAP70Q T 90.1/99.1
D5901 1750001810 S.DIO L1SS400T1G T 205.6/79.4
D5921 1750001810 S.DIO L1SS400T1G T 193.7/80.5
D5941 1750001810 S.DIO L1SS400T1G T 200.7/96.8
D5951 1750001810 S.DIO L1SS400T1G T 209.4/97.9
D5961 1750001810 S.DIO L1SS400T1G T 191.0/96.8
D5962 1750001810 S.DIO L1SS400T1G T 192.2/96.8
IC4001 1110008540 S.IC 62783G-S18-R T 130.5/111.3
IC4002 1110008540 S.IC 62783G-S18-R T 118.3/111.8
IC4021 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 107.6/109.1
IC4022 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 107.6/104.3
IC4051 1130018870 S.IC TC7WH14FKLJ T 99.8/27.2
IC4061 1110006921 S.IC S-80845CNMC-B86T2G T 176.8/102.7
IC4071 1130018870 S.IC TC7WH14FKLJ T 188.1/104.4
IC4072 1110005140 S.IC NJM3403AV-TE1-#ZZZB T 156.7/101.2
IC4261 6910027620 S.DC TPS54418RTER T 179.4/70.4
IC4262 1130007021 S.IC TC7S66FU (TE85LF) T 183.1/82.6
IC4321 1180004970 S.REG XC6222D251MR-G T 174.6/87.0
IC4331 1180004740 S.REG S-1313D33-M5T1U3 T 180.0/92.6
IC4341 1180004740 S.REG S-1313D33-M5T1U3 T 174.6/91.9
IC4361 1180004430 S.REG XC6209F502MR-G T 117.6/18.5
IC4371 1180004800 S.REG XC6222D181MR-G T 184.2/92.6
IC4381 6910028150 S.DC ADP5075ACBZ-R7 T 115.9/12.5
IC4401 1110007400 S.IC BGA616 T 4.8/82.1
IC4661 1110007400 S.IC BGA616 T 73.5/49.8
IC4662 1180004430 S.REG XC6209F502MR-G T 105.1/44.6
IC4901 1140018901 S.IC STM32F429IGT6 T 177.2/45.5
IC4902 1130018050 S.IC SN74AHCT367PWR T 151.4/40.2
IC5001 1130019460 S.IC GT24C256A-2ZLI-TR T 173.9/25.2
IC5011 1110005771 S.IC S-80942CNMC-G9CT2G T 191.4/23.0
IC5051 1130016460 S.IC R2A20169SA T 144.5/102.0
IC5061 1130017400 S.IC MC74HC4094ADTR2G T 131.9/100.8
IC5062 1130017400 S.IC MC74HC4094ADTR2G T 68.7/84.4
IC5063 1130017400 S.IC MC74HC4094ADTR2G T 79.2/86.2
IC5064 1130017400 S.IC MC74HC4094ADTR2G T 72.5/115.5
IC5081 1130011551 S.IC RX-4581NB-F T 205.9/45.7
IC5101 1140018370 S.IC 5CEFA9F23I7N T 144.6/77.0
IC5102 6910024650 S.IC 74LVC2G17GW125 T 202.5/108.4
IC5103 6910024650 S.IC 74LVC2G17GW125 T 198.2/108.4
IC5104 1130018770 S.IC S25FL127SABMFI100 T 214.9/57.2
IC5161 1180004430 S.REG XC6209F502MR-G T 94.3/103.2
IC5181 1110009190 S.IC LTC6401IUD-20#TRPBF T 105.5/80.3
IC5201 1190005200 S.IC AD9645BCPZRL7-80 T 125.2/85.9
IC5241 1110009190 S.IC LTC6401IUD-20#TRPBF T 105.7/91.8
IC5281 1190004630 S.IC ISL5961IAZ T 123.7/69.7
IC5401 1130019760 S.IC IPS6404L-SQ-SPN T 145.1/55.3
IC5441 1130012160 S.IC SN74LVC1GU04DCKR T 117.8/54.4
IC5451 1130017950 S.IC SN65LVDS1DBVR T 116.4/58.8
IC5461 1130014260 S.IC SN74LVC2GU04DCKR T 123.4/58.5
IC5491 1130012160 S.IC SN74LVC1GU04DCKR T 123.9/54.4
IC5501 1110007930 S.IC PCM1681PWPR T 88.8/32.6
IC5502 1110008890 S.IC NJU7056F3-TE2-#ZZZH T 56.3/24.5
IC5521 1110006570 S.IC TS462CPT T 56.9/37.4
IC5541 1110004050 S.IC NJM3404AV-TE1-#FMZB T 133.8/6.4
IC5561 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 112.6/49.5
IC5581 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 105.3/60.6
IC5601 1110009480 IC STA540-HF
IC5621 1190004280 S.IC PCM1802DBR T 73.1/32.5
IC5651 1130009981 S.IC TC7W53FK (TE85LF) T 58.2/18.5
IC5661 1130009981 S.IC TC7W53FK (TE85LF) T 178.5/16.0
IC5681 1130009981 S.IC TC7W53FK (TE85LF) T 58.2/11.8
IC5911 1110005610 S.IC NJM2058V-TE1-#ZZZB T 204.6/89.7
IC5921 1110005610 S.IC NJM2058V-TE1-#ZZZB T 195.7/89.7
Q4021 1590005220 S.TRA LDTA114YET1G T 123.1/100.3
Q4022 1590004690 S.TRA LDTC143ZET1G T 125.6/100.3
Q4023 1590004690 S.TRA LDTC143ZET1G T 125.6/98.2
Q4061 1530004140 S.TRA L2SC4081RT1G T 179.9/103.0
Q4062 1590005220 S.TRA LDTA114YET1G T 176.9/110.9
Q4063 1550000241 S.FET TPCF8107LF T 177.9/107.4
Q4071 1590004690 S.TRA LDTC143ZET1G T 183.9/104.9
Q4072 1590005220 S.TRA LDTA114YET1G T 183.9/107.5
Q4073 1530004140 S.TRA L2SC4081RT1G T 165.2/101.7
Q4141 1530004140 S.TRA L2SC4081RT1G T 143.5/10.2
Q4142 1530004140 S.TRA L2SC4081RT1G T 175.2/11.4
Q4161 1590005220 S.TRA LDTA114YET1G T 146.3/10.1
Q4162 1530004620 S.TRA 2SCR553P5T100 T 146.5/6.6
Q4341 1560002210 S.FET RE1J002YNTCL T 170.4/81.9
Q4342 1590005220 S.TRA LDTA114YET1G T 175.0/94.8
Q4401 1590005220 S.TRA LDTA114YET1G T 19.2/54.7
Q4402 1590004690 S.TRA LDTC143ZET1G T 19.2/52.2
Q4421 1530003091 S.TRA 2SC4213-B (TE85RF) T 10.4/57.0
Q4422 1590005220 S.TRA LDTA114YET1G T 17.1/54.7
Q4423 1590004690 S.TRA LDTC143ZET1G T 15.0/54.7
Q4424 1590004690 S.TRA LDTC143ZET1G T 15.0/52.2
Q4426 1590004690 S.TRA LDTC143ZET1G T 21.3/52.2
Q4427 1590005220 S.TRA LDTA114YET1G T 21.3/54.7
Q4631 1590005220 S.TRA LDTA114YET1G T 106.1/51.5
Q4632 1590004690 S.TRA LDTC143ZET1G T 106.1/48.9
Q4641 1530004560 S.TRA 2SC3356G-B-AE2-R T 73.5/68.2
Q4642 1590005220 S.TRA LDTA114YET1G T 100.9/54.5
Q4643 1590005220 S.TRA LDTA114YET1G T 106.1/54.5
Q4644 1590004690 S.TRA LDTC143ZET1G T 104.1/54.5
Q4661 1590005220 S.TRA LDTA114YET1G T 104.1/51.5
Q4662 1590005220 S.TRA LDTA114YET1G T 100.8/51.5
Q4663 1590004690 S.TRA LDTC143ZET1G T 104.1/48.9
Q4701 1590004690 S.TRA LDTC143ZET1G T 12.7/99.0
Q4702 1530004140 S.TRA L2SC4081RT1G T 13.9/96.3
Q4871 1590005220 S.TRA LDTA114YET1G T 113.3/97.8
Q4872 1590004690 S.TRA LDTC143ZET1G T 116.9/97.8
Q4881 1530004560 S.TRA 2SC3356G-B-AE2-R T 80.5/109.0
Q4882 1590005220 S.TRA LDTA114YET1G T 113.3/93.3
Q4883 1590005220 S.TRA LDTA114YET1G T 113.3/95.3
Q4884 1590004690 S.TRA LDTC143ZET1G T 116.9/95.3
