7-1
REF PART
DESCRIPTION QTY.
NO. NO.
REF PART
DESCRIPTION QTY.
NO. NO.
SECTION 7 MECHANICAL PARTS
*: Refer to “BOARD LAYOUTS” for the location.
Screw abbreviations
A, B0, BT: Self-tapping PH: Pan head BS: Brass NI: Nickel ZU: Zinc SUS: Stainless
J3001 6510028411 MR-DS-01-2 1
J3003 6510028411 MR-DS-01-2 1
MF3001 2710001060 FD128025HB-N (2N7R1) 1
W3001 8900011050 OPC-1109 1
W3002 8920003240 CAB-1390 1
W3003 8970024742 1.5D COAXIAL 65MM-2 C31/W17D PHL 1
W3006 8900009031 OPC-902A (P1N30L130) 1
W3007 8900015920 OPC-1142A (P1N16L110) 1
W3008 8970024752 1.5D COAXIAL 330MM-2 C31/W17D PHL 1
W3010 8900018134 OPC-1303B-4 1
W3011 8900009031 OPC-902A (P1N30L130) 1
W3012 8900009031 OPC-902A (P1N30L130) 1
W3020 8970024232 1.5D COAXIAL 390MM-2 (F/I) C31/C31 1
W3022 8920003300 CAB-1395 1
W3023 8970024083 1.5D COAXIAL 180MM-3 C31/C31 1
W3025 8970024442 1.5D COAXIAL 510MM-2 (B) C31/C31 1
EP3001 6950000710 USBC-3 1
MP3001 8010018824 2429 CHASSIS-4 1
MP3002 8110007703 2429 T-COVER-3 1
MP3003 8110011720 4100 B-COVER ZAM 1
MP3004 8110011730 4100 PA COVER ZAM 1
MP3005 8930057191 2429 EARTH PLATE-1 2
MP3006 8930057980 RUBBER REG (N) SJ-5023K 4
MP3007 8930102230 4100 D-SUB PLATE 1
MP3009 8820000530 FLANGE BOLT M4 × 8 NI 1
MP3011 8810010670 SET SCREW H M4 × 30 ZC3 2
MP3012 8810008661 PH BT M3 × 8 NI-ZC3 38
MP3013 8810005771 BIND M3 × 8 ZK3 BLACK 14
MP3014 8810009991 PH BT M3 × 8 NI-ZK3 4
MP3016 8930058100 2429 DC PLATE 1
MP3025 8810007231 SET SCREW H M3 × 8 ZC3 8
MP3026 8810007231 SET SCREW H M3 × 8 ZC3 2
MP3027 8810007231 SET SCREW H M3 × 8 ZC3 1
MP3028 8810007231 SET SCREW H M3 × 8 ZC3 2
MP3029 8930102460 4100 IC CLIP 1
MP3030 8930070510 THERMAL SHEET (BF) TC-600HS-1.4 2
[CHASSIS UNIT]
[MAIN UNIT]
[CONNECT UNIT]
[PA UNIT]
J6101* 6510028210 SJ050010 (TMP-J01X-V6) 1
J6401* 6510028210 SJ050010 (TMP-J01X-V6) 1
F6701* 5220000440 FHA040-01 1
F6702 5210001430 11930011 (BFLP 5A 58V) 1
EP6327* 6910018760 GLASS D=1.0 L=15MM 2
EP6602* 6510018330 F4053A 1
EP6603* 6510018330 F4053A 1
MP6401 8860001640 4100 RUG 1
MP6402 8860001640 4100 RUG 1
MP6403 8860001640 4100 RUG 1
MP6404 8860001640 4100 RUG 1
[FILTER UNIT]
[FRONT UNIT]
[LOGIC UNIT]
REF PART
DESCRIPTION QTY.
NO. NO.
J4141* 6510023671 TCS4480-0141577 1
J4161* 6450002470 JY-3510A 1
J4401* 6510028210 SJ050010 (TMP-J01X-V6) 1
J4421* 6510028210 SJ050010 (TMP-J01X-V6) 1
J4701* 6510028210 SJ050010 (TMP-J01X-V6) 1
J5071* 6510026540 UBB-4R-D14T-4D (LF) (SN) 1
J5081* 6510021861 BH-800.4GG 1
BT5081 3020000110 CR-2032L/BK 1
MP4201* 8510019710 3182 PLL CASE 1
MP4381* 8510019800 3183 FILTER CASE 1
MP5181* 8510021830 3765 S-CASE 1
MP5241* 8510021830 3765 S-CASE 1
MP5282* 8510021830 3765 S-CASE 1
MP5421* 8510019800 3183 FILTER CASE 1
REF PART
DESCRIPTION QTY.
NO. NO.
J7711* 6510023120 CD6109SA1J0 1
J7721* 6510023120 CD6109SA1J0 1
J7751* 6450002650 BNC-6252H7 1
MP7701 8930077910 2590 M2-SPRING 1
REF PART
DESCRIPTION QTY.
NO. NO.
J7001* 6510028210 SJ050010 (TMP-J01X-V6) 1
J7311* 6510028210 SJ050010 (TMP-J01X-V6) 1
J7321* 6510028210 SJ050010 (TMP-J01X-V6) 1
REF PART
DESCRIPTION QTY.
NO. NO.
SP8001 2510002060 057D0401 1
W8002 8910000070 FFC-1008 (P0.5N6L50) 1
W8003 8910000070 FFC-1008 (P0.5N6L50) 1
W8004 8900018000 OPC-1344A (P1N10L70) 1
W8005 8900015120 OPC-942B (P1N10L170) 1
W8006 8920003260 CAB-1380 1
W8007 8920001660 CAB-1174 1
MP8001 8210034770 3715 FRONT PANEL (D) ASSEMBLY-1 1
MP8003 8930092130 3715 LCD HOLDER 1
MP8004 8610015670 KNOB N-430 ASSEMBLY 1
MP8007 8610015630 KNOB N-429 1
MP8008 8930091880 3715 B-KEY (SC) 1
MP8009 8930091890 3715 F-PACKING (ORION) 1
MP8010 8930092250 3715 LCD SPONGE 1
MP8012 8510021570 3715 SHIELD CASE 1
MP8013 8930092350 3715 SP HOLDER 1
MP8014 8310084000 3570 D-COVER 1
MP8015 8930088990 3570 SHAFT 1
MP8016 8930089100 3570 SPRING 1
MP8017 8930069020 O-RING (BG) 2
MP8018 8810008661 PH BT M3×8 NI-ZC3 11
MP8019 8810008661 PH BT M3×8 NI-ZC3 4
MP8022 8930058780 2577 SHEET 1
MP8024 8820001180 2417 SCREW 2.6×16 8
MP8025 8930053730 O-RING (AI) (KSK) 8
MP8026 8930082360 3340 JACK CAP 1
MP8027 8930082490 O-RING (CH) (TOP) 1
MP8028 8510021640 3726 CASE ASSEMBLY 1
MP8029 8930092550 3715 A-KEY (A) (SC) 1
MP8030 8930057950 DOUBLE SIDE TAPE (AH) 1
MP8031 8810008661 PH BT M3×8 NI-ZC3 2
REF PART
DESCRIPTION QTY.
NO. NO.
DS9001 5030004580 RFE430V-AZH-DNN-000 1
