Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
6-3
[MAIN UNIT] [MAIN UNIT]
R4026 7030015970 S.RES RMC1/16S-103JTH (10 k) T 113.0/105.1
R4028 7030015970 S.RES RMC1/16S-103JTH (10 k) T 111.2/106.1
R4029 7030016380 S.RES RMC1/16S-183JTH (18 k) T 111.2/105.1
R4030 7030016110 S.RES RMC1/16S-473JTH (47 k) T 111.2/103.1
R4031 7030015900 S.RES RMC1/16S-470JTH (47) T 111.2/102.1
R4032 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 116.6/100.4
R4035 7030015910 S.RES RMC1/16S-101JTH (100) T 106.0/111.3
R4036 7030016110 S.RES RMC1/16S-473JTH (47 k) T 103.9/110.2
R4037 7030016220 S.RES RMC1/16S-563JTH (56 k) T 103.9/109.2
R4038 7030015980 S.RES RMC1/16S-333JTH (33 k) T 103.9/108.1
R4039 7030016280 S.RES RMC1/16S-331JTH (330) T 103.9/107.1
R4040 7030015970 S.RES RMC1/16S-103JTH (10 k) T 102.1/106.1
R4041 7030016110 S.RES RMC1/16S-473JTH (47 k) T 103.9/104.1
R4042 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 103.9/106.1
R4043 7030016330 S.RES RMC1/16S-153JTH (15 k) T 103.9/105.1
R4044 7030015980 S.RES RMC1/16S-333JTH (33 k) T 103.9/103.1
R4045 7030015980 S.RES RMC1/16S-333JTH (33 k) T 102.1/103.1
R4046 7030015910 S.RES RMC1/16S-101JTH (100) T 103.9/101.0
R4047 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 116.6/102.3
R4048 7030015910 S.RES RMC1/16S-101JTH (100) T 106.1/106.9
R4049 7030015910 S.RES RMC1/16S-101JTH (100) T 106.1/102.1
R4051 7030015920 S.RES RMC1/16S-221JTH (220) T 95.7/24.3
R4052 7030015920 S.RES RMC1/16S-221JTH (220) T 96.7/24.3
R4053 7030015920 S.RES RMC1/16S-221JTH (220) T 97.7/24.3
R4054 7030015920 S.RES RMC1/16S-221JTH (220) T 98.7/24.3
R4055 7030015920 S.RES RMC1/16S-221JTH (220) T 99.7/24.3
R4056 7030015920 S.RES RMC1/16S-221JTH (220) T 100.7/24.3
R4057 7030015920 S.RES RMC1/16S-221JTH (220) T 101.7/24.3
R4061 7030015990 S.RES RMC1/16S-683JTH (68 k) T 175.1/105.4
R4062 7030016090 S.RES RMC1/16S-223JTH (22 k) T 173.3/105.4
R4063 7030016020 S.RES RMC1/16S-104JTH (100 k) T 177.4/105.4
R4064 7030016090 S.RES RMC1/16S-223JTH (22 k) T 179.2/105.4
R4065 7030016050 S.RES RMC1/16S-102JTH (1 k) T 178.2/109.8
R4066 7030016030 S.RES RMC1/16S-154JTH (150 k) T 176.8/109.4
R4067 7030016220 S.RES RMC1/16S-563JTH (56 k) T 179.6/109.4
R4071 7030016510 S.RES RMC1/16S-4R7JTH (4.7) T 157.0/110.9
R4072 7030016050 S.RES RMC1/16S-102JTH (1 k) T 139.9/108.1
R4074 7030016050 S.RES RMC1/16S-102JTH (1 k) T 158.0/110.9
R4075 7030015920 S.RES RMC1/16S-221JTH (220) T 147.0/110.9
R4076 7030015920 S.RES RMC1/16S-221JTH (220) T 146.0/110.9
R4077 7030015920 S.RES RMC1/16S-221JTH (220) T 145.0/110.9
R4078 7030015920 S.RES RMC1/16S-221JTH (220) T 144.0/110.9
R4079 7030015920 S.RES RMC1/16S-221JTH (220) T 143.0/110.9
R4080 7030015920 S.RES RMC1/16S-221JTH (220) T 142.0/110.9
R4081 7030015920 S.RES RMC1/16S-221JTH (220) T 141.0/110.9
R4082 7030016050 S.RES RMC1/16S-102JTH (1 k) T 150.7/108.1
R4083 7030016050 S.RES RMC1/16S-102JTH (1 k) T 185.3/106.0
R4084 7030016110 S.RES RMC1/16S-473JTH (47 k) T 185.3/107.8
R4085 7030016110 S.RES RMC1/16S-473JTH (47 k) T 191.0/105.1
R4086 7030016050 S.RES RMC1/16S-102JTH (1 k) T 184.3/102.6
R4087 7030016060 S.RES RMC1/16S-105JTH (1M) T 186.1/102.6
R4090 7030016110 S.RES RMC1/16S-473JTH (47 k) T 158.0/104.5
R4091 7030015910 S.RES RMC1/16S-101JTH (100) T 161.7/103.5
R4092 7030016000 S.RES RMC1/16S-823JTH (82 k) T 162.2/101.3
R4093 7030016000 S.RES RMC1/16S-823JTH (82 k) T 162.6/102.6
R4094 7030016050 S.RES RMC1/16S-102JTH (1 k) T 137.7/107.3
R4095 7030015970 S.RES RMC1/16S-103JTH (10 k) T 163.2/101.3
R4101 7030016110 S.RES RMC1/16S-473JTH (47 k) T 151.7/102.1
R4102 7030016110 S.RES RMC1/16S-473JTH (47 k) T 151.7/100.1
R4103 7030016110 S.RES RMC1/16S-473JTH (47 k) T 153.3/104.1
R4104 7030016110 S.RES RMC1/16S-473JTH (47 k) T 153.3/98.0
R4105 7030016050 S.RES RMC1/16S-102JTH (1 k) T 151.7/103.1
R4106 7030016050 S.RES RMC1/16S-102JTH (1 k) T 151.7/99.1
R4107 7030018130 S.RES RMC1/16SK472FTH (4.7 k) T 192.1/19.6
R4108 7030016900 S.RES RMC1/16SK102FTH (1 k) T 190.3/18.6
R4109 7030016050 S.RES RMC1/16S-102JTH (1 k) T 192.1/18.6
R4110 7030015910 S.RES RMC1/16S-101JTH (100) T 151.7/101.1
R4111 7030016050 S.RES RMC1/16S-102JTH (1 k) T 158.0/98.0
R4112 7030016020 S.RES RMC1/16S-104JTH (100 k) T 162.6/100.0
R4113 7030016020 S.RES RMC1/16S-104JTH (100 k) T 162.6/99.0
R4114 7030016230 S.RES RMC1/16S-394JTH (390 k) T 161.2/99.4
R4115 7030016110 S.RES RMC1/16S-473JTH (47 k) T 162.6/98.0
R4116 7030015920 S.RES RMC1/16S-221JTH (220) T 160.8/98.0
R4141 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 146.5/12.0
R4142 7030016330 S.RES RMC1/16S-153JTH (15 k) T 142.9/12.0
R4143 7030015980 S.RES RMC1/16S-333JTH (33 k) T 144.7/12.0
R4144 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 144.7/13.0
R4145 7030016090 S.RES RMC1/16S-223JTH (22 k) T 173.5/12.5
R4146 7030016330 S.RES RMC1/16S-153JTH (15 k) T 174.5/8.9
R4147 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 173.5/10.7
R4148 7030016110 S.RES RMC1/16S-473JTH (47 k) T 173.5/8.9
R4161 7030016270 S.RES RMC1/16S-151JTH (150) T 142.9/8.3
R4162 7030015970 S.RES RMC1/16S-103JTH (10 k) T 142.9/7.3
R4181 7030016560 S.RES RMC1/16SJPTH T 32.2/26.4
R4182 7030015930 S.RES RMC1/16S-471JTH (470) T 32.9/39.5
R4183 7030015930 S.RES RMC1/16S-471JTH (470) T 36.0/39.5
R4261 7030016560 S.RES RMC1/16SJPTH T 182.6/85.6
R4263 7030016030 S.RES RMC1/16S-154JTH (150 k) T 176.7/72.1
R4264 7030016050 S.RES RMC1/16S-102JTH (1 k) T 178.7/72.9
R4265 7030017370 S.RES RGC1/16SC183DTH (18 k) T 171.7/74.8
R4266 7030017370 S.RES RGC1/16SC183DTH (18 k) T 173.1/74.3
R4267 7030018480 S.RES RGC1/16SC563DTH (56.0 k) T 174.6/74.3
R4268 7030016910 S.RES RGC1/16SC393DTH (39 k) T 175.6/74.3
R4321 7030021080 S.RES RMC1/2-2R7JTE (2.7) T 175.9/83.4
R4341 7030015970 S.RES RMC1/16S-103JTH (10 k) T 170.4/84.2
R4382 7030015910 S.RES RMC1/16S-101JTH (100) T 114.0/15.3
R4385 7030016330 S.RES RMC1/16S-153JTH (15 k) T 114.0/13.3
R4386 7030016400 S.RES RMC1/16S-564JTH (560 k) T 116.7/4.6
R4387 7030016400 S.RES RMC1/16S-564JTH (560 k) T 116.2/15.3
R4388 7030016910 S.RES RGC1/16SC393DTH (39 k) T 115.8/14.3
R4389 7030016820 S.RES RGC1/16SC333DTH (33.0 k) T 117.6/14.3
R4401 7030015930 S.RES RMC1/16S-471JTH (470) T 2.4/74.3
R4402 7030016150 S.RES RMC1/16S-100JTH (10) T 3.8/74.8
R4403 7030015930 S.RES RMC1/16S-471JTH (470) T 2.4/75.2
R4404 7030016130 S.RES RMC1/16S-150JTH (15) T 1.9/84.7
R4405 7030016370 S.RES RMC1/16S-271JTH (270) T 6.6/85.1
R4406 7030016570 S.RES RMC1/16S-180JTH (18) T 7.7/85.1
R4407 7030016370 S.RES RMC1/16S-271JTH (270) T 8.7/85.1
R4411 7030016210 S.RES RMC1/16S-121JTH (120) T 7.7/81.6
R4421 7030016050 S.RES RMC1/16S-102JTH (1 k) T 14.2/56.8
R4422 7030016050 S.RES RMC1/16S-102JTH (1 k) T 13.2/56.8
R4423 7030015970 S.RES RMC1/16S-103JTH (10 k) T 10.4/61.5
R4424 7030015920 S.RES RMC1/16S-221JTH (220) T 8.1/66.7
R4425 7030016210 S.RES RMC1/16S-121JTH (120) T 10.4/66.7
R4426 7030016490 S.RES RMC1/16S-391JTH (390) T 10.8/77.0
R4427 7030016460 S.RES RMC1/16S-181JTH (180) T 18.9/83.3
R4428 7030016050 S.RES RMC1/16S-102JTH (1 k) T 13.5/51.8
R4441 7030016400 S.RES RMC1/16S-564JTH (560 k) T 11.2/79.5
R4451 7030016210 S.RES RMC1/16S-121JTH (120) T 18.5/64.5
R4452 7030016210 S.RES RMC1/16S-121JTH (120) T 18.5/79.5
R4471 7030016210 S.RES RMC1/16S-121JTH (120) T 23.1/64.5
R4472 7030016210 S.RES RMC1/16S-121JTH (120) T 23.1/85.2
R4491 7030016210 S.RES RMC1/16S-121JTH (120) T 27.7/64.5
R4492 7030016210 S.RES RMC1/16S-121JTH (120) T 27.7/85.2
R4511 7030016210 S.RES RMC1/16S-121JTH (120) T 33.8/64.5
R4512 7030016210 S.RES RMC1/16S-121JTH (120) T 33.8/85.2
R4531 7030016210 S.RES RMC1/16S-121JTH (120) T 39.9/64.5
R4532 7030016210 S.RES RMC1/16S-121JTH (120) T 39.9/85.2
R4551 7030016210 S.RES RMC1/16S-121JTH (120) T 46.0/64.5
R4552 7030016210 S.RES RMC1/16S-121JTH (120) T 46.0/85.2
R4571 7030016210 S.RES RMC1/16S-121JTH (120) T 50.5/64.5
R4572 7030016210 S.RES RMC1/16S-121JTH (120) T 50.5/85.2
R4591 7030016210 S.RES RMC1/16S-121JTH (120) T 55.7/63.7
R4592 7030016210 S.RES RMC1/16S-121JTH (120) T 55.0/85.2
R4611 7030016210 S.RES RMC1/16S-121JTH (120) T 61.0/63.6
R4612 7030016210 S.RES RMC1/16S-121JTH (120) T 60.3/85.2
R4631 7030016460 S.RES RMC1/16S-181JTH (180) T 17.4/61.2
R4632 7030019460 S.RES RMC1/8-561JTP (560) T 64.9/61.4
R4633 7030016460 S.RES RMC1/16S-181JTH (180) T 70.9/58.2
R4634 7030016460 S.RES RMC1/16S-181JTH (180) T 83.1/58.2
R4635 7030016090 S.RES RMC1/16S-223JTH (22 k) T 76.9/59.4
R4636 7030019460 S.RES RMC1/8-561JTP (560) T 90.4/67.5
R4641 7030016460 S.RES RMC1/16S-181JTH (180) T 69.1/67.3
R4642 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 72.8/61.3
R4643 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 74.7/61.3
R4644 7030016150 S.RES RMC1/16S-100JTH (10) T 71.0/67.3
R4645 7030016180 S.RES RMC1/16S-680JTH (68) T 74.5/70.7
R4646 7030016460 S.RES RMC1/16S-181JTH (180) T 83.0/69.5
R4647 7030016090 S.RES RMC1/16S-223JTH (22 k) T 107.6/55.6
R4661 7030016460 S.RES RMC1/16S-181JTH (180) T 66.5/59.8
R4662 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 73.8/55.8
R4663 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 72.0/54.7
R4664 7030016410 S.RES RMC1/16S-561JTH (560) T 66.5/55.2
R4665 7030016050 S.RES RMC1/16S-102JTH (1 k) T 73.8/54.7
R4666 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 72.0/53.7
R4667 7030015910 S.RES RMC1/16S-101JTH (100) T 66.5/54.2
R4668 7030016410 S.RES RMC1/16S-561JTH (560) T 66.5/53.2
R4669 7030016130 S.RES RMC1/16S-150JTH (15) T 70.1/50.7
R4670 7030016280 S.RES RMC1/16S-331JTH (330) T 70.1/51.6
R4671 7030016280 S.RES RMC1/16S-331JTH (330) T 71.4/51.2
R4672 7030016130 S.RES RMC1/16S-150JTH (15) T 68.6/47.1
R4673 7030016050 S.RES RMC1/16S-102JTH (1 k) T 77.7/55.3
R4674 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 76.7/55.3
R4675 7030016410 S.RES RMC1/16S-561JTH (560) T 77.2/49.8
R4676 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 78.7/55.3
R4677 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 79.7/55.3
R4678 7030015910 S.RES RMC1/16S-101JTH (100) T 78.2/49.8
R4679 7030016410 S.RES RMC1/16S-561JTH (560) T 79.2/49.8
R4680 7030016050 S.RES RMC1/16S-102JTH (1 k) T 87.4/55.3
R4681 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 86.4/55.3
R4682 7030016410 S.RES RMC1/16S-561JTH (560) T 86.9/49.8
R4683 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 88.4/55.3
R4684 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 89.4/55.3
R4685 7030015910 S.RES RMC1/16S-101JTH (100) T 87.9/49.8
R4686 7030016410 S.RES RMC1/16S-561JTH (560) T 88.9/49.8
R4687 7030016460 S.RES RMC1/16S-181JTH (180) T 93.5/51.4
R4688 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 101.4/49.0
R4689 7030019460 S.RES RMC1/8-561JTP (560) T 95.3/53.0
R4691 7030015920 S.RES RMC1/16S-221JTH (220) T 102.5/48.5
R4692 7030015920 S.RES RMC1/16S-221JTH (220) T 21.3/50.4
R4695 7030016400 S.RES RMC1/16S-564JTH (560 k) T 68.5/65.9
R4698 7030016400 S.RES RMC1/16S-564JTH (560 k) T 87.1/69.1
R4701 7030016340 S.RES RMC1/16S-393JTH (39 k) T 9.1/105.3
R4702 7030016340 S.RES RMC1/16S-393JTH (39 k) T 9.1/107.1
R4703 7030016090 S.RES RMC1/16S-223JTH (22 k) T 16.6/106.0
R4704 7030015970 S.RES RMC1/16S-103JTH (10 k) T 15.9/95.9
R4705 7030015910 S.RES RMC1/16S-101JTH (100) T 14.9/101.4
R4706 7030016090 S.RES RMC1/16S-223JTH (22 k) T 14.9/100.4
R4707 7030015970 S.RES RMC1/16S-103JTH (10 k) T 14.4/99.4
R4709 7030016460 S.RES RMC1/16S-181JTH (180) T 18.5/89.6
R4721 7030016400 S.RES RMC1/16S-564JTH (560 k) T 8.8/97.2
R4731 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 22.4/91.5
R4732 7030016210 S.RES RMC1/16S-121JTH (120) T 22.4/92.5
R4736 7030016210 S.RES RMC1/16S-121JTH (120) T 24.1/115.3
R4751 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 29.9/91.5
R4752 7030016210 S.RES RMC1/16S-121JTH (120) T 29.9/92.5
R4756 7030016210 S.RES RMC1/16S-121JTH (120) T 30.5/115.1
R4771 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 37.5/91.5
R4772 7030016210 S.RES RMC1/16S-121JTH (120) T 37.5/92.5
R4774 7030016560 S.RES RMC1/16SJPTH T 35.3/110.8
R4776 7030016210 S.RES RMC1/16S-121JTH (120) T 37.6/113.7
R4791 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 45.0/91.5
R4792 7030016210 S.RES RMC1/16S-121JTH (120) T 45.0/92.5
R4794 7030016560 S.RES RMC1/16SJPTH T 44.0/113.7
R4796 7030016210 S.RES RMC1/16S-121JTH (120) T 45.0/116.5
R4811 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 52.7/92.8
R4812 7030016210 S.RES RMC1/16S-121JTH (120) T 53.9/90.9
R4814 7030016560 S.RES RMC1/16SJPTH T 51.1/112.7
R4816 7030016210 S.RES RMC1/16S-121JTH (120) T 53.2/115.5
R4841 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 60.5/92.8
To Next Page
Loading...
