Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
6-19
[MIC UNIT]
D8562 1790001810 S.VAR AVR-M1005C080MTABB T 10.2/20.8
C8568 4030022140 S.CER GRM033B31H102KA12D T 16.7/17.0
J8561 6510030290 CON ICOM-CCBPM08MCC
J8562 6510022621 S.CON
10FMN-BMTTR-A-TBT (LF) (SN)
T 20.9/11.0
