2-3
• PA UNIT
J6703
BUFFER
(Q6101)
DRIVE AMPLIFIER
(Q6202)
5 A FUSE
(F2)
DRIVE AMPLIFIER
(Q6201)
POWER AMPLIFIER
(Q6303)
POWER AMPLIFIER
(Q6304)
J6701
BUFFER
(IC6402)
BUFFER
(IC6401)
COOLING FAN DRIVER
(Q6501)
POWER SUPPLY
LINE SWITCH
(Q6702)
BUFFER
(IC6101)
POWER AMPLIFIER
(Q6302)
POWER AMPLIFIER
(Q6301)
J6101
J6401
CURRENT SENSOR
(IC6502)
CURRENT SENSOR
(IC6503)
J6501
BUFFER
(IC6201)
