FREQUENCY SETTING
D 1 MHz quick tuning step
The quick tuning step function allows you to change
the frequency in 1 MHz steps when rotating the
tuning dial.
Push [TS] one or more times until the 1 MHz tuning
step indicator, “ √ ,” appears above the 1 MHz
indicator.
USB
R X
BLANKBLANK
S1 3
5
7
9
20 40
60
dB
AGCANT
VFO
1
Quick tuning step
indicator
10 Hz tuning
1 Hz tuning
momentarily
2 sec.2 sec.
2 sec.
1 MHz tuning
Programmable step tuning
(100 Hz –100 kHz)
Selectable for each mode.
momentarilymomentarily
USB
R X
USB
R X
USB
R X
USB
R X
[TS] SWITCH FLOW CHART
■ Dial lock function
The dial lock function prevents accidental changes
caused by the tuning dial. The lock function
electronically locks the dial.
Push [LOCK] momentarily to toggle the lock function
ON and OFF.
• “LOCK” appears in the function display while the lock
function is activated.
USB
R X
BLANKBLANK
S1 3
5
7
9
20 40
60 dB
AGCANT
VFO
1
LOCK
“LOCK” appears while the lock
function is activated.
[LOCK]
