5-1 PREPARATION
■ REQUIRED TEST EQUIPMENT
5 - 1
SECTION 5 ADJUSTMENT PROCEDURES
EQUIPMENT
DC power supply
GRADE AND RANGE
Output voltage : 7.2 V DC
Current capacity : 5 A or more
EQUIPMENT
Digital multimeter
GRADE AND RANGE
Input impedance : 10 MΩ/V DC or better
Top view
Soldering
DC cable here
—
+
DC POWER
SUPPLY
• DC POWER CABLE CONNECTION
