Icom IC-V8 Service Manual

SPEAKER
J2
OPT
EP5
MIC
J3
J6
SP1
ANTENNA
EXT. SPEAKER
EXT. MIC
S801
ENCODER
E
UP
DN
GND
BATT
12
12
9 - 1
9 - 1 MAIN UNIT
SECTION 9 BOARD LAYOUTS
(TOP VIEW)
The combination of this page and the next page shows
the unit layout in the same configuration as the actual
P.C. Board.

Icom IC-V8 Specifications

General

Frequency Range	136-174 MHz
Power Output	5.5 W
Mode	FM
Receiver Sensitivity	0.16 μV (12dB SINAD)
Channel Spacing	12.5/25 kHz
Voltage	7.2 V DC
