3
1 PANEL DESCRIPTION
■ Function display
qTRANSMIT INDICATOR
➥ Appears while transmitting. (p. 15)
➥ Flashes while transmitting with the one-touch PTT func-
tion. (p. 16)
wFREQUENCY READOUT
Shows the operating frequency, channel names, set mode
contents, etc.
• Frequency decimal point flashes while scanning. (p. 38)
•“d” appears in place of the 1st digit while the DTMF memory
function is in use. (p. 45)
eOUTPUT POWER INDICATORS
“LOW” appears when low output power; “LOW” and “MID”
appear when low mid output power; “MID” appears when
middle output power is selected
rBUSY INDICATOR (p. 13)
➥ Appears when a signal is being received or the squelch
is open.
➥ Flashes while the monitor function is activated.
tAUDIO MUTE INDICATOR (p. 14)
Appears when the audio mute function is activated via mi-
crophone control.
