S.=Surface mount
6 - 5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1180002390 S.REG S-812C33AMC-C2N-T2 T 3.4/27.9
IC2 1180002370 S.REG R1111N321B-TR T 19.5/27.8
IC50 1130011630 S.IC AD73311ARS T 13.7/19.6
IC101 1130008360 S.IC TC7SHU04FU (TE85L) B 32.5/2.5
IC103 1130006890 S.IC TC7S04FU (TE85R) T 34/5.9
IC151 1130010920 S.IC AMBE-2020 T 27.9/16.1
IC202 1130010460 S.IC TC7SH08FU (TE85L) B 29.6/7.9
IC203 1110005730 S.IC S-80928CNMC-G8Y-T2 B 30/27.5
IC204 1140010770 S.IC HD64F3687FP (EMPTY) B 29.9/18.1
IC251 1110005290 S.IC NJM2115V-TE1 B 16.7/21.9
IC252 1110005430 S.IC CMX589AD5 B 16.7/13.6
IC253 1110006200 S.IC NJM13404V-TE1 B 16.6/6.1
IC254 1130004200 S.IC TC4S66F (TE85R) B 28/4.1
IC351 1120002980 S.IC MAX3226EAE-T T 9.7/6.1
Q50 1510000770 S.TR 2SA1586-GR (TE85R) T 9.6/11
Q51 1590000430 S.TR DTC144EUA T106 B 8.7/23.2
Q201 1590000430 S.TR DTC144EUA T106 B 33.1/9.1
Q202 1590000430 S.TR DTC144EUA T106 B 35.8/10.3
Q251 1590000430 S.TR DTC144EUA T106 B 35.6/5.1
Q252 1590000430 S.TR DTC144EUA T106 B 35.8/7.8
Q301 1590000430 S.TR DTC144EUA T106 B 7.3/25.9
Q302 1590000430 S.TR DTC144EUA T106 B 2.3/25.5
Q303 1590000430 S.TR DTC144EUA T106 B 4.8/25.9
Q305 1590001660 S.TR XP4312 (TX) B 23/8.1
Q306 1590001660 S.TR XP4312 (TX) B 26/8.1
Q400 1510000770 S.TR 2SA1586-GR (TE85R) B 13.2/27.5
Q401 1590000430 S.TR DTC144EUA T106 B 9.8/25.9
D151 1790001240 S.DIO MA2S728-(TX) T 29.2/6.9
D152 1790001250 S.DIO MA2S111-(TX) B 22.7/23.7
X101 6050011240 S.XTL CR-708 (16.384 MHz) T 30.5/2.5
X201 6050011700 S.XTL CR-760 (9.8304 MHz) T 30.5/27.7
L50 6200003960 S.COL MLF1608A 1R0K-T T 11.8/11.9
L151 6200003960 S.COL MLF1608A 1R0K-T B 16.1/27.2
L201 6200003960 S.COL MLF1608A 1R0K-T B 24.6/12.1
L351 6200003960 S.COL MLF1608A 1R0K-T T 14.2/9.4
R1 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 17.1/26.7
R2 7030000180 S.RES MCR10EZHJ 22
Ω
(220) T 12.9/26.8
R50 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 8.2/19.7
R51 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 8.2/23.3
R52 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 11.1/21.6
R53 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 13.7/18.9
R54 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 6.6/22.9
R55 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 12.5/22.4
R56 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 12.5/24.2
R57 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 17.3/23.5
R58 7030010040 S.RES ERJ2GE-JPW B 11.1/22.6
R59 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 7.7/11.2
R60 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 7.2/12.5
R100 7030010040 S.RES ERJ2GE-JPW T 13.5/12.1
R101 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 32.6/4.4
R102 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 35.1/2.8
R103 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 35.8/5.4
R151 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 29.6/5.5
R152 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 31.4/6.9
R201 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 30.3/10.4
R202 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 29.3/10.4
R203 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 28.3/10.4
R204 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 27.1/10.4
R205 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 31.3/7.5
R206 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 32.3/11
R209 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 27.8/27
R211 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 25.5/25.1
R212 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 22.4/22.3
R216 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 22.3/20
R217 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 22.3/21
R218 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 24.3/11
R219 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 26.1/10.4
R221 7030010040 S.RES ERJ2GE-JPW B 24.5/25.1
R251 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 20.1/24.7
R252 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 20.1/23.7
R253 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 11.3/13.9
R254 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 11.3/12.9
R255 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 10.9/10.9
R256 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 15.8/18.9
R257 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 13.1/9.3
R258 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 17.8/18.9
R260 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 16.8/18.9
R261 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 11.3/9.6
R262 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 17.1/11.8
R264 7310004610 S.TRI EVM-2WSX80 B15 (104) T 16.9/9
R267 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 17.7/8.7
R268 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 25.3/4.8
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R269 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 15.9/8.7
R270 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 28.5/1.6
R308 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 1.8/16.9
R309 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 2.8/16.9
R315 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 6.2/16
R316 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 2.8/11.3
R317 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 10/17
R318 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 2.3/18.2
R400 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 10.2/28.7
R401 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 10.2/27.7
C1 4550006250 S.TAN TEESVA 1A 106M8L T 8/26.7
C2 4550006250 S.TAN TEESVA 1A 106M8L T 8/28.9
C5 4030017460 S.CER ECJ0EB1E102K B 5.7/28.2
C7 4550005980 S.TAN TEESVA 1A 475M8L T 13.6/28.9
C8 4030016930 S.CER ECJ0EB1A104K T 17.1/28.7
C9 4550006250 S.TAN TEESVA 1A 106M8L T 24.1/28.9
C10 4030016930 S.CER ECJ0EB1A104K T 22/26.8
C11 4550006480 S.TAN TEESVA 1C 475M8L T 14.5/24.8
C50 4030016930 S.CER ECJ0EB1A104K T 7.2/18.7
C51 4030016970 S.CER ECJ0EB1C223K T 7.7/22
C53 4030016930 S.CER ECJ0EB1A104K T 6.6/21.1
C54 4550006250 S.TAN TEESVA 1A 106M8L T 9.4/14.5
C55 4030016930 S.CER ECJ0EB1A104K T 8.7/21
C56 4030016950 S.CER ECJ0EB1A473K B 11.1/20.6
C57 4030016930 S.CER ECJ0EB1A104K T 8.7/18.4
C58 4030016930 S.CER ECJ0EB1A104K T 17.3/15.7
C102 4540000070 S.TRI TZY2Z100A001 T 24.4/3.4
C103 4030017590 S.CER ECJ0EC1H070C T 34.3/2
C104 4030016930 S.CER ECJ0EB1A104K B 34.4/1.2
C106 4030016930 S.CER ECJ0EB1A104K T 35.1/3.8
C150 4550000460 S.TAN TEESVA 1C 105M8L T 15.3/14.1
C151 4030016930 S.CER ECJ0EB1A104K T 22.4/25.1
C152 4030016930 S.CER ECJ0EB1A104K T 29/25.1
C153 4030016930 S.CER ECJ0EB1A104K T 18.9/15.5
C154 4030016930 S.CER ECJ0EB1A104K T 18.8/10
C155 4030016930 S.CER ECJ0EB1A104K T 22.9/7
C156 4030016930 S.CER ECJ0EB1A104K T 27.6/6.4
C157 4030016930 S.CER ECJ0EB1A104K T 37.1/10.6
C159 4030016930 S.CER ECJ0EB1A104K T 37.1/16.6
C201 4030016930 S.CER ECJ0EB1A104K B 27.8/7.6
C202 4030017590 S.CER ECJ0EC1H070C B 33.1/28.1
C203 4030016930 S.CER ECJ0EB1A104K B 32.5/25.8
C204 4030017390 S.CER ECJ0EC1H180J T 27.2/26.7
C205 4030016930 S.CER ECJ0EB1A104K B 29.2/25.2
C206 4030016790 S.CER ECJ0EB1C103K B 32.1/27.6
C207 4540000080 S.TRI TZY2R200A001 T 35.4/26.4
C250 4030016930 S.CER ECJ0EB1A104K B 13.5/24.2
C252 4030017490 S.CER C1608 JB 1A 105K-T B 17.8/24.6
C253 4030017400 S.CER ECJ0EC1H220J B 14.8/18.9
C255 4030017490 S.CER C1608 JB 1A 105K-T B 10.8/15.5
C256 4030016930 S.CER ECJ0EB1A104K B 20/8.7
C257 4030017030 S.CER ECJ0EB1A273K B 20.3/18.3
C258 4030017030 S.CER ECJ0EB1A273K B 20.3/19.3
C259 4030017760 S.CER ECJ0EB1H222K T 16/11.8
C260 4030017490 S.CER C1608 JB 1A 105K-T B 13.2/3.6
C261 4030016930 S.CER ECJ0EB1A104K B 21.4/4.9
C262 4030017490 S.CER C1608 JB 1A 105K-T B 19.9/3.5
C263 4030016930 S.CER ECJ0EB1A104K B 24.9/2.8
C333 4030017460 S.CER ECJ0EB1E102K T 9.1/12.9
C351 4030011810 S.CER C1608 JB 1A 224K-T T 4.5/7.1
C352 4030011810 S.CER C1608 JB 1A 224K-T T 5.7/9.4
C353 4030011810 S.CER C1608 JB 1A 224K-T T 3.5/4.9
C354 4030011810 S.CER C1608 JB 1A 224K-T T 3.5/3.6
C355 4030011600 S.CER C1608 JB 1E 104K-T T 15/7.3
C401 4550006250 S.TAN TEESVA 1A 106M8L B 17.4/28.9
J301 6510018440 S.CNR AXN430C330P B 5.3/13.8
6-2 OPTIONAL UNIT UT-118
[MAIN UNIT]
