Section 1
1
ACCESSORIES
Accessory attachments
Antenna D
Connect the supplied or an optional antenna to the an-
tenna connector.
CAUTION:
• NEVER carry the transceiver by holding only the
antenna.
• DO NOT connect any antenna other than those
listed in OPTIONS in INSTRUCTIONS w that is
provided with the transceiver.
• Transmitting without an antenna may damage the
transceiver.
Battery pack D
To attach or detach the battery pack:
Attach or detach the battery pack, as illustrated to the
right.
Belt clip D
To attach the belt clip:
Remove the battery pack from the transceiver, if it is q
attached.
Slide the belt clip in the direction of the arrow until the w
belt clip locks in place, and makes a ‘click’ sound.
To detach the belt clip:
Remove the battery pack from the transceiver, if it is q
attached.
Lift the tab up ( w q), and slide the belt clip in the direc-
tion of the arrow (w).
To attach
To attach
To detach
To detach
To Next Page
