Front / Top Panel - Cube DJ mini
This is unbalanced MIC level input for a dynamic microphone.
This potentiometer controls the input level of the mic.
MIC INPUT CONNECTOR FOR INPUTS 1/2
MIC INPUT GAIN LEVEL CONTROL
HEADPHONE LEVEL CONTROL:
HEADPHONE OUTPUT:
MASTER LEVEL CONTROL:
This potentiometer controls the output level of the headphone output.(Ch.3 & 4)
This output jack accepts a standard 1/4" stereo TRS headphone connector.
This potentiometer controls the master output level of the analog
outputs.(Ch.1 & 2)
