ICON Cube - Cube G

Rear / Side Panel - Cube G
Line Outs
L
USB
RLR
Line In
S/PDIF
Out In
Midi I/O
InOut
USB 2.0 CONNECTOR
LINE INPUTS 1/2
LINE OUTPUTS 1/2
S/PDIF COAXIAL I/O CONNECTORS
MIDI I/O CONNECTORS
Connect it with the provided USB cable to your Mac/PC's USB connector.
Your Mac/PC must have a USB2.0 connector in order to run the full speed
of Cube G.
These are unbalanced analog inputs on standard 1/4 TS connectors at
–10dB line level.
These are unbalanced analog outputs on standard 1/4 TS connectors at
+6dBU line level.
S/PDIF digital input and output on coaxial RCA connectors. The digital
input is selected via the Cube G's software control panel, while the digital
output will be sent to the coaxial.
MIDI input and output on standard 5-pin DIN connectors
″
″
