H
USB
Stereo Out
Rear / Side Panel - Cube Mini
Connect it with the provided USB cable to your computer's USB
connector. Your computer must have a USB2.0 connector i
This output jack accepts a standard 1/4" stereo TRS headphone
connector.
These are unbalanced stereo output on standard 1/4" TS connectors at
+6dBU line level.
These
USB 2.0 CONNECTOR:
HEADPHONE OUTPUT:
STEREO OUTPUT:
INPUT GAIN LEVEL CONTROL FOR HI-Z INPUTS 1 & 2:
to maximize
the performance of Cube Mini.
potentiometer control the input level of their associated guitar
input 1 & 2.
Gain
G1 G2
Gain
Rear Panel - Cube 4Nano
