Software control panel
The “Playback” and “Monitor” mixers work like a matrix mixer. Activate and
adjust the correspondence input or output channel level. They are very useful
and make your inputs and outputs very flexible. You may route any of your
input(s) to any output(s).
Playback Mixer
Hardware inputs level metering
Cube
Cube Pro
Cube G
Cube Mini
Cube 4 Nano
Cube DJ
Cube DJ mini
Hardware outputs level metering
Cube
Cube Pro
Cube G
Cube Mini
Cube 4 Nano
Cube DJ
Cube DJ mini
– Ch 1,2 input level metering
– Ch 1,2 & Ch 3,4 input level metering
– Ch 1,2 & S/PDIF input level metering
– Ch 1,2 input level metering
– Ch 1,2 & S/PDIF input level metering
– Ch 1,2 & Ch 3,4 input level metering
– Ch 1,2 input level metering
Showing the input level for the hardware input channel.
– Ch 1,2 output level metering
– Ch 1,2 & Ch 3,4 output level metering
– Ch 1,2 & S/PDIF output level metering
– Ch 1,2 output level metering
– Ch 1,2 & S/PDIF output level metering
– Ch 1,2 & S/PDIF output level metering
–Ch 1,2 & Ch 3,4 output level metering
Showing the output level for the hardware output channel.
Software outputs level metering
Cube
Cube Pro
Cube G
Cube Mini
Cube 4
Cube DJ
Cube DJ mini
Hardware outputs level metering
Cube
Cube Pro
Cube G
Cube Mini
Cube 4 Nano
Cube DJ
Cube DJ mini
– Ch 1,2 output level metering
– Ch 1,2 & Ch 3,4 output level metering
– Ch 1,2 & S/PDIF output level metering
– Ch 1,2 output level metering
Nano – Ch 1,2 & S/PDIF output level metering
– Ch 1,2 & Ch 3,4 output level metering
– Ch. 1,2 & Ch 3,4 output level metering
Showing the input level for the software input channel.
– Ch 1,2 output level metering
– Ch 1,2 & Ch 3,4 output level metering
– Ch 1,2 & S/PDIF output level metering
– Ch 1,2 output level metering
– Ch 1,2 & S/PDIF output level metering
– Ch 1,2 & S/PDIF output level metering
–Ch 1,2 & Ch 3,4 output level metering
Showing the output level for the hardware output channel.
Monitor Mixer
Playback Mixer
Monitor Mixer
