TUNNEL MASTER JR MANUAL
System Hardware 29
The Optional Report/Receipt Printer
Introduction
The Epson TM-T811 thermal printer is utilized by the Tunnel Master Jr.
system for both the report and receipt printer. These printers can be
purchased as an option to the base system or purchased and added to the
system after initial installation.
Helpful Tip ☺
Please refer to the Operator’s Manual supplied with the printer for proper care
and maintenance of your printer.
If you are using the Epson Dot Matrix printer, please be sure to check the
dipswitch settings of the printer. DSW1 dipswitch 3 should be the only
dipswitch set to ON all of the others should be off. The dipswitches are
located on the bottom of the printer. You will have to remove the small door
covering the dipswitches.
Exterior
