ICT DIN Series User Manual

Innovative Circuit Technology Ltd. 7
NC/C PINS
NO/C PINS
CONDITION
Open
Closed
Fuse Alarm
• Activate Alarm Form C Contact is checked
• One or more blown or missing fuse
System Under - Voltage Alarm
• Activate Alarm Form C Contact is checked
• System Voltage is below the set value
System Over - Voltage Alarm
• Activate Alarm Form C Contact is checked
• System voltage is above the set value
System Over - Current Alarm
• Activate Alarm Form C Contact is checked
• System current is above the set value
Alarm Input #1 - #4
• Activate Alarm Form C Contact is checked
• Digital Alarm is triggered
Output Over - Current Alarm #1 - #6
• Activate Alarm Form C Contact is checked
• Output Current is above the set value
Output Under - Current Alarm #1 - #6
• Activate Alarm Form C Contact is checked
• Output Current is below the set value
No power to unit
Closed
Open
Activate Alarm Form C Contact is checked and
no fault occurred
All Activate Alarm Form C Contact is not checked
Table 2: Form “C” Alarm
PIN
DESCRIPTION
1
Alarm Input # 1
2
Common
3
Alarm Input # 2
4
Common
5
Alarm Input # 3
6
Common
7
Alarm Input # 4
8
Common
Table 3: Alarm Input Connector Pin-out
