Comfosplit IKARO HW – User and Installer manual EN
© Ideal Clima - Page 65 of 68
CONNECTION WITH 3 SPEED CHRONOTHERMOSTAT (TGCL29)
N.B.: The use of a thermostat for speed management excludes the control of the battery water temperature
INSTALLATION FINALIZATION
After completing the electrical and hydraulic
connection, remove the wedge and snap the
unit in place to the bottom of the mounting
plate.
Make sure the unit is properly attached to the
slots at the bottom of the mounting plate, by
pulling gently the unit toward yourself. The unit
should not rotate away from the wall.
