TILT-A-WAY
HYDRAULIC VERTICAL PIVOT GATE
BALANCE SYSTEM SPRING TENSIONER UNIT
DRAWING HYJG-251
(2 ASSEMBLIES INCLUDED)
REF NO. PART NO. DESCRIPTION REQ’D NO.
1 N/A Operator Frame
2 N/A Safety Device Brackets
3 Tension Spring
TWO137 500 Pound Blue As required
TWO138 1000 Pound Yellow As required
TWO139 1500 Pound Orange As required
TWO112 1750 Pound Green As required
TWO140 2000 Pound Red As required
TWO113 2500 Pound White As required
4 Front Spring Connector
FGO168 500 or 1000 Pound Spring 2
FGO170 1500 or 1750 Pound Spring 2
FGO171 2000 or 2500 Pound Spring 2
5 TWO104 Clevis Pin 2
6 Rear Spring Connector
FGO139 500 or 1000 Pound Spring 2
FGO157 1500 or 1750 Pound Spring 2
FGO159 2000 or 2500 Pound Spring 2
8 FGO130 Tension Screw with End Nut Welded
2
9 TWO133 Safety Compression Spring 2
10 FGO131 Safety Nut 2
11 TWO108 Set Screw 2
12 N/A ½” x 3” Hex Head Bolt 2
13 N/A ½” Lock Nut 2
14 N/A 1” SAE Washer 4
15 FGO174 Pipe Spacer 2
16 ID1061 Cotter Pin 2
17 PEO611 Safety Switch 2
18 FGO161 Safety Release Bar 2
