Page #48 background imageLoading...
Page #48 background image
EMX Industries, Inc. Tech support: 216-834-0761 3/6
ULT-PLG_Rev1.8_082619 technical@emxinc.com
Automatic
Sensitivity
Boost
DIP Switch 8
The Automatic Sensitivity Boost causes the sensitivity
to increase following initial detection. This feature is useful
to prevent dropout when detecting high-bed vehicles.
The sensitivity returns to its normal setting after the vehicle
exits the loop. The decimal point on the ULTRAMETER display
indicates ASB is on.
ASB Enabled
on
ASB Disabled
off
Presence
DIP Switch 7
Infinite presence mode causes the output to remain in detect
as long as the vehicle remains on the loop. Normal presence
mode causes the output to reset after 5 minutes. Do not use
Normal presence mode for reversing loop applications.
Normal
on
Infinite
off
Detect-On-Stop
DIP Switch 6
The Detect-On-Stop (DOS
®
) feature requires that a vehicle
must come to a complete stop over the loop for a minimum of
1-2 seconds before Output B activates. DOS
®
will not function
if in Loop Fault mode. Do not use DOS
®
feature for reversing
loop applications.
DOS
®
On
on
DOS
®
Off
off
Output B
DIP Switch
Output B is configurable for four possible modes.
In Pulse on Entry/Exit mode, Output B will be activated for
approximately 500ms when a vehicle is entering or exiting
the detection zone. In B same as A, relay B has the same
output as relay A. In Loop Fault mode, the relay will trigger
if a loop fault occurs.
Mode
5
4
Pulse on Entry
on
on
Pulse on Exit
on
off
B same as A
off
on
Loop Fault
off
off
Fail Safe / Secure
DIP Switch 3
The Fail Safe setting causes the ULT-PLG to activate the
presence output in the event of a loop failure. The Fail Secure
setting will cause the ULT-PLG not to activate the presence
output in the event of a loop failure. Do not use Fail Secure
for reversing loop applications.
Fail Safe
on
Fail Secure
off
Frequency
Settings
DIP Switch
DIP switches 2 and 1 are used to assign the loop operation
frequency. The primary purpose of the Frequency Setting
is to allow the installer the ability to set different operating
frequencies for multi-loop installations and is recommended
to prevent crosstalk/interference from multiple loops.
2
1
Low
on
on
Medium Low
on
off
Medium High
off
on
High
off
off
