Specifications
Model# HYJG 1
Operator Size 28” W x 50” T x 120”L
Operator Weight 1,800 lbs.
Maximum Barrier Size 375 lbs
Voltage Phase Hz Cir. Reg. Amps. Act. Draw
208/240 VAC 1 60 20 14
208/240 VAC 3 60 10 9
480 VAC 3 60 5 3
Control Board Voltage
24 VDC
For 24 VDC motor operator
Voltage Hz Cir. Reg. Amps.
120 VAC 60 15 (for battery charger and accessories)
Motor Voltage Control Board Voltage
24 VDC 24 VDC
Operator Speed to 90* 16-20 Seconds
Hydraulic Fluid Citgo-CP (this hydraulic fluid is blue in color)
Maximum Operating Temperature 70 C / 158 F
Note: Hydraulic pump pressure factor set at 385 PSI do not exceed this setting
Note: Wire size is very important. Measure the distance from your power source to the gate
operator location. For wire sizes consult the NEC (National Electric Code).
Recommended Wire Size
208/240 VAC AMPS 20 SINGLE PHASE
Length of circuit in feet
20’-60’ 60’-100’ 100’–160’ 160’–240’ for circuit length greater than 240’ consult a licensed electrician
Wire size 12 10 8 6
208/240 VAC AMPS 10 THREE PHASE
Length of circuit in feet
20’–120’ 120’–180’ 180’–300’ 300’–480’ 480’–760’ 760’–1220’ 1220’–1540’ 1540’–1940’ 1940’–2440’
Wire size 14 12 10 8 6 4 3 2 1
460/480 VAC AMPS 5 THREE PHASE
Length of circuit in feet
20’–500’ 500’–800’ 800’–1280’ 1280’–2040’ 2040–3260’ 3260’–5200’ 5200’–8240’
Wire size 14 12 10 8 6 4 3
120 VAC AMPS 15
Length of circuit in feet
20’-60’ 60’-100’ 100’–160’ 160’–280’ for circuit length greater than 260’ consult a licensed electrician
Wire size 12 10 8 6
