16
TILT-A-WAY HYJG 1
BASIC ELECTRICAL HARDWARE 240-VAC THREE PHASE
DRAWING HYJG-210 ON PAGE 17 SINGLE GATE
DRAWING HYJG-211 ON PAGE 18 MASTER GATE
1 P00961 ENCLOSURE 1
2 PEO640 CIRCUIT BREAKER 1
3 100117B POWER SUPPLY (24-VDC) 1
4 PEO202I INTERFACE BOARD 1
5 PEO202L LOGIC BOARD 1
6 PEO202H MOTOR BOARD 1
7 PEO202C CONNECTING CORD 1
8 PEO611 SAFETY SWITCH 2
9 PEO963A LIMIT SWITCH (nc) 4
10 100234 POTENTIOMETER 1
11 PEO223 ½” ROMEX 3
12 PEO275 ¾” ROMEX 3
13 100127 ALARM 1
14 PEO268-1 OVERLOAD RELAY 1
15 PEO605A RELAY SOCKET 5 PIN 1
16 PEO679 RELAY 5 PIN SAFETY 1
17 PEO620 END BARRIER (not shown) 1
18 PEO621 GREEN TERMINAL BLOCK 1
19 PEO644 BROWN TERMINAL BLOCK 2
20 PEO645 YELLOW TERMINAL BLOCK 2
21 PEO646 ORANGE TERMINAL BLOCK 2
22 100128 CONTACTOR 1
DRAWING HYJG-212 ON PAGE 19 SLAVE GATE
REF PART NO. DESCRIPTION QTY
1 PEO292 ENCLOSURE 1
2 PEO640 CIRCUIT BREAKER 1
3 100117B POWER SUPPLY (24-VDC) 1
6 PEO202H MOTOR BOARD 1
8 PEO611 SAFETY SWITCH 2
9 PEO963A LIMIT SWITCH (nc) 4
10 100234 POTENTIOMETER 1
11 PEO223 ½” ROMEX 3
12 PEO275 ¾” ROMEX 2
14 PEO268-1 OVERLOAD RELAY 1
15 PEO605A RELAY SOCKET 5 PIN 1
16 PEO679 RELAY 5 PIN SAFETY 1
17 PEO620 END BARRIER (not shown) 1
18 PEO621 GREEN TERMINAL BLOCK 1
19 PEO644 BROWN TERMINAL BLOCK 2
20 PEO645 YELLOW TERMINAL BLOCK 2
21 PEO646 ORANGE TERMINAL BLOCK 2
22 100128 CONTACTOR 1
