TILT-A-WAY
HYDRAULIC VERTICAL PIVOT GATE
HYJG 1 HYDRAULIC SYSTEM
DRAWING HYJG-252
REF NO. PART NO. DESCRIPTION REQ’D NO.
1 TWO575-1 Hydraulic Cylinder 1
2 100125
100126
100135
Hydraulic Pump & Reservoir Set Single Phase
Hydraulic Pump & Reservoir Set 24 VDC
Hydraulic Pump & Reservoir Set Three Phase
1
3 TWO528 #6 MORB X #6 MJIC Adapter 2
4 TWO402 Short 3/8 Pressure Hose 36” 1
5 TWO164 Long 3/8” Pressure Hose 87” 1
6 TWO579 90 degree Elbow 1
7 TWO578 90 degree Elbow (long) 1
8 TWO520
TWO462
In Tank Heater AC Unit
In Tank Heater DC Unit
1
9 TWO524 Pressure Relief Valve (factory set at 385 psi) 1
10 Manual Override Valves 2
11 100123 Cylinder slow down driver open 1
12 100123 Cylinder slow down driver closed 1
13 Sight Gauge 1
14 100121 Proportional Valves 1
