IDEAL TILT-A WAY HYJG 1 - Page 93

87
TILT-A-WAY
HYDRAULIC VERTICAL PIVOT GATE
HYJG 1 BARRIER CARRIAGE
DRAWING HYJG-245
REF NO. PART NO. DESCRIPTION REQ’D NO.
1A FGO147-C Barrier Carriage Frame (standard) 1
1B FGO147-B Barrier Carriage Frame (short) 1
1C FGO147-D Barrier Carriage Frame (use with 1 ½” x 3” hex bolt)
2 TWO101 Pillow Block Bearing 2
3 N/A 1/2” Hex Nut 4
4 N/A 1/2” Lock Washer 4
5 N/A 1/2” SAE Flat Washer 4
6 N/A 1/2” X 4 1/2” Flat Head Bolt 4
7 N/A 1” SAE Flat Washer 4
8 ID1006 3/16” X 1 1/2” Stainless Cotter Pin 2
9 N/A 5/8” Nylock Nut 5-(1A) 1-(1B)
10 N/A 5/8” x 3 1/4” Hex Head Bolt 5-(1A) 1-(1B)
11 N/A 3/8” Hex Nut 12
12 N/A 3/8” Lock Washer 12
13 N/A 3/8” X 1 1/4” Hex Head Bolt 8
14 N/A 1/2” X 5 1/2” Hex Head Bolt 1
15 N/A 1/2” Nylock Nut 1
16 N/A 3/8”X 1 1/2” Hex Head Bolt 4
17 N/A 3/8” Flat Washer 8
18 FGO759 Steel Sway Brace Bracket 2
