IDEAL TILT-A WAY HYJG 1

TILT-A-WAY HYJG 1
HYDRAULIC CYLINDER WITH COMPONENTS
ITEM
PART NUMBER
QTY
DESCRIPTION
1
100234
1
STRING POTENTIOMETER
2
100235
2
U BOLT
3
FGO194
1
PLASTIC RUNNER BEARING
4
FGO198
1
ROD END PIVOT SHAFT
5
FGO199
1
PLASTIC RUB WASHER
6
FGO208
1
BEARING SLEEVE PRESSURE WASHER
7
G00120
1
FOOT CLEVES
8
G00123
2
PLATE WASHER
9
G00137
1
ACTUATOR ROD HYJG
10
G00138
1
ACTUATING TRACK
11
G00141
2
LIMIT SWITCH MOUNTING PLATE
12
G00142
1
ACTUATOR BLOCK
13
G00152
1
POTENTIOMETER BRACKET
14
G00153
1
STRING BRACKET
15
ID1031
2
E Ring
16
NA
1
1 1/2 - 6 X 3 1/2 Hex Bolt
17
NA
1
1 1/2 - 6 Hex Jam Nut
18
NA
6
1/2 -13 Hex Nut
19
NA
6
1/2 Lock Washer
20
NA
6
1/2 - 13 X 1 3/4 Hex Bolt
21
NA
3
1/2 - 13 X 1 1/4 Hex Bolt
22
NA
1
6 ORB X 6 FJIC LONG 90 DEG
23
NA
1
6 ORB X 6 FJIC 90 DEG
24
NA
4
3/8 - 16 Hex Nut
25
NA
4
1/4 Lock Washer
26
NA
1
GREASE FITTING
27
NA
4
3/8 Lock Washer
28
NA
3
1/2 Lock Washer
29
NA
1
8 - 32 X 3/4 Machine Screw
30
NA
2
8 - 32 X 1 Machine Screw
31
NA
8
8 - 32 X 1 1/2 Machine Screw
32
NA
4
1/4 - 20 Hex Nut
33
NA
8
SPACER
34
NA
4
1/4 Flat Washer
35
NA
4
1/4 -20 X 1 Hex Bolt
36
NA
2
8 -32 X 1/2 Machine Screw
37
NA
2
8 - 32 X 3/8 Machine Screw
38
NA
16
8 - 32 Hex Machine Screw Nut
39
NA
16
NO. 8 Lock Washers
40
NA
2
3/4 - 10 Hex Nut
41
NA
1
3/4 Lock Washer
42
PEO963A
4
LIMIT SWITCH
43
TWO118
1
BEARING ROD END
44
TWO575-1
1
CYLINDER
