IDEAL TILT-A WAY HYJG 1

1 1
2 2
3 3
4 4
A A B B C C D D
SHEET 1 OF 1
DRAWN CHECKED QA MFG APPROVED T Henry
9/20/2017 11/5/2019
DWG NO HYJG-256
TITLE
HYJG 24 VOLT DC BATTERY LOCATION
SIZE
C
SCALE
Ideal Mfg., Inc.
REV
0.10 : 1
MASS
1612.5 lbmass
PROJECTION
REMOVE ALL BURRS
UNLESS OTHER WISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
.XX ` .01
.XXX ` .005
FRACTION `
1
32
ANGLES ` 1~
DRILLED HOLE `
1
64
2011 Harnish Blvd.
Billings MT 59101
PARTS LIST
DESCRIPTIONQTYITEM
12 VOLT BATTERY21 WEATHER GUARD13 BATTERY SHELF12
1
1
3
2
TILT-A-WAY
HYDRAULIC VERTICAL POVOT GATE
HYJG 24 VOLT DC
BATTERY LOCATION
92
RIGHT HAND OPERATOR
SHOWN LEFT HAND OPPOSITE
