39 MENU OPERATION
STATE OF OUTPUTS
To view the current status of the Pump, Fan, Spark Generator
and Gas Valve press ENTER and the following screen will be
displayed.
MENU
Vent System
Maximum Flow Temperature
Outside Sensor Slope
Fault Help
Exit
Enter
Press “-” until the following screen is displayed.
MENU
State of Inputs
State of Outputs
Service Mode Minimum Rate
Service Mode Maximum Rate
Exit
Enter
Press ENTER and a screen similar to the following will be
displayed.
State of Outputs
Pump:
Fan (Target 3000rpm):
Spark Generator:
Gas Valve:
On @ 50%
3000rpm
Off
On
Exit
Press “+” and “-“ to view the full list.
Press EXIT twice to return to normal operation.
SERVICE MODE MINIMUM RATE
This feature will run the burner at minimum rate. Note that a
CH demand has to already be present for the feature to be
active. To activate the feature press ENTER and the following
screen will be displayed.
MENU
Vent System
Maximum Flow Temperature
Outside Sensor Slope
Fault Help
Exit
Enter
Press “-” until the following screen is displayed.
MENU
State of Outputs
Service Mode Minimum Rate
Service Mode Maximum Rate
Show Efficiency Level
Exit
Enter
Press ENTER and the following screen will be displayed.
Service Mode
Minimum Rate
Fan Target 2000rpm
Fan Actual 1950rpm
Exit
Press EXIT twice to return to normal operation.
SERVICE MODE MAXIMUM RATE
This feature will run the burner at maximum rate. Note that
a CH demand has to already be present for the feature to be
active. Gas rate will reduce as ow temperature approached
80
o
C. To activate the feature press ENTER and the following
screen will be displayed.
MENU
Vent System
Maximum Flow Temperature
Outside Sensor Slope
Fault Help
Exit
Enter
Press “-“ until the following screen is displayed.
MENU
Service Mode Minimum Rate
Service Mode Maximum Rate
Show Efficiency Level
System Frost Protection
Exit
Enter
Press ENTER and the following screen will be displayed.
Service Mode
Maximum Rate
Fan Target 5000rpm
Fan Actual 4950rpm
Exit
Press EXIT twice to return to normal operation.
EFFICIENCY LEVEL
To view the efciency level of the boiler press ENTER and the
following screen will be displayed.
MENU
Vent System
Maximum Flow Temperature
Outside Sensor Slope
Fault Help
Exit
Enter
Press “-“ until the following screen is displayed.
MENU
Service Mode Maximum Rate
Show Efficiency Level
System Frost Protection
Reset Service Time
Exit
Enter
Press ENTER and a screen similar to following will be
displayed.
High
Efficiency
1346
Hours
Efficiency Level
Exit
29260
Hours
Super
Efficiency
Press EXIT twice to return to normal operation.
