3.11. AutoFill
The ITL-40 has a .250 Amp ground output driver that can be custom configured to turn on and off based on tank
levels. The feature will disable and shut off the output if the ITL-40 is in a sensor error condition once the error
condition has been resolved the output will continue to operate. (Note only available on 123340-XX units)
3.11.1. Enabling the AutoFill output
Enable the AutoFill feature by entering the password LRRL RLLL.
The display will scroll "FILL ON" to indicate that the feature has been enabled.
3.11.2. Disabling the AutoFill output
Disable the AutoFill feature by entering the password LRRL RLLR.
The display will scroll "FILL OFF" to indicate that the feature has been disabled.
3.11.3. Setting the AutoFill turn on level
The turn on level can be customized from Empty to 7/8 of a tank by entering a password (Section 4). Example if
you want the AutoFill output to turn on when the tank level falls to 1/4 of a tank or below you would enter the
following password RRRL LLRL. Once the password has been entered the display will briefly display 1/4 of a tank
to indicate the level has been set.
3.11.4. Setting the AutoFill turn off level
The turn off level can be customized from Full to 1/8 of a tank by entering a password (Section 4). Example if you
want the AutoFill output to turn off when the tank level rises to 3/4 of a tank or below you would enter the following
password RRRR LLRL. Once the password has been entered the display will briefly display 3/4 of a tank to
indicate the level has been set.
