OPERATION MANUAL
MANUAL P/N:118253 PRINTED: 6/12/19
9. Technical details
9.1. Technical details
ITL40 (Intelli-Tank Level 40)
Power consumption
@13.8VDC (25ºC)
@27.6VDC (25ºC)
Operational temperature range
SAE J1939 proprietary, 250 Kbits/second
Class 1 proprietary, 425 bits/second
Protected .250 Amp Ground output
Internal thermal fuse
Reverse voltage protection (pins 1 and 12 of connector)
CAN buses protected to 24V
ESD voltage protected to SAE J1113 specification for heavy duty trucks
Transient voltage protected to SAE J1113 specification for heavy duty trucks
Dimensions (W x H x D) in inches [mm]
3.185 [80.90] x 5.125 [130.17] x 2.150 [54.61]
9.2. WEEE (Waste of Electrical and Electronic Equipment) directive
This symbol [crossed-out wheeled bin WEEE Annex IV] indicates separate collection of waste electrical and
electronic equipment in the European Union countries.
Please do not throw the equipment into the domestic refuse.
Each individual European Union member state has implemented the WEEE regulations into national law in
slightly different ways. Please follow your national law when you want to dispose of any electrical or electronic
products.
More details can be obtained from your national WEEE recycling agency.
This device complies with the European Regulations for Electromagnetic Compatibility (EMC) of the European
Union and it is equipped with the CE mark. This unit must be used in accordance with the details specified within
this manual.
