MANUAL P/N:118253 PRINTED: 6/12/19
2. System Overview
2.1. Scope
The Intelli-Tank Level 40 (ITL40) is designed to display a liquid’s volume to an eighth of a tank level accuracy through
180-degree viewable ultra-bright LEDs. An Intelli-Tank Level 40 set as a MASTER uses a 0-5 PSI (0-34.47 kPa,
0-0.3447 bar) pressure sensor to obtain tank level information and then relays that information along the
communication line(s) (1-Wire or CAN) to ITL40’s set as REMOTES. Multiple REMOTE units can be linked to the
MASTER tank level.
2.2. Part numbers Standard with auto fill
Tank Level Gauge C1 – p/n 118404-01 123340-01 – Red LEDs
p/n 118404-02 123340-02 – Amber LEDs
p/n 118404-03 123340-03 – Yellow LEDs
p/n 118404-04 123340-04 – Green LEDs
p/n 118404-05 123340-05 – Blue LEDs
p/n 118404-06 123340-06 – 2 Red, 2 Yellow, 2 Blue, 2 Green rows of LEDs
Labels C1 – p/n 117691 – water (blue)
p/n 117692 – foam (red)
p/n 117693 – foam (green)
Pressure Sensor C1 – p/n 200-00093 – 0 to 5 PSI (0 to 34.47 kPa, 0 to 0.3447 bar) gage
Adapter bushing C1 – p/n 102219 – ¾ to ¼ NPT
Installation Harness C1 – p/n 118485-10 – Master display, 10 feet
p/n 118485-20 – Master display, 20 feet
p/n 118485-30 – Master display, 30 feet
p/n 118485-40 – Master display, 40 feet
p/n 118695 – Remote display
Terminating resistor (CAN) C1 – p/n DT06-3S-P006
“Y” connector (CAN) C1 – p/n DT04-3P-P007
Operation Manual C1 – p/n 118253
One Page Manual C1 – p/n 118252
2.3. Modes of Operation
Master When the ITL40 display is calibrated with a proper pressure signal it automatically becomes a MASTER
display and will send tank level information along the communication line(s) (either 1-wire or CAN) to all
other REMOTE displays.
Remote ITL40 displays are initially shipped as REMOTE displays. A REMOTE display only requires power,
ground and communications line(s) (either 1-wire or CAN). The REMOTE display mimics the MASTER
display’s LEDs by reading the appropriate information on the communication line(s).
