10 iDirect Evolution X5 Satellite Router Installation and Safety Manual
Mechanical and Environmental Specifications
3.1 Mechanical and Environmental Specifications
Ensure that the installation site can accommodate the mechanical and environmental
specifications of the IDU. The Evolution X5 Satellite Router mechanical and environmental
specifications are presented in Table 3.
Table 3. Mechanical and Environmental Specifications
Category Description
Dimensions W 11.5 in (29.2 cm) x D 9.9 in (25.1 cm) x H 2.0 in (5.1) cm
Weight 4.4 lbs (1.99 Kg)
Heat Dissipation 16 W (54.6 BTU/Hour)
Airflow Natural Convection Cooling
Ambient Temperature
Operational:
Storage:
32° F to 122° F (0° C to 40° C) at Sea Level
a
104° F to 122° F (40° C to 50° C) at Sea Level
b
32° F to 113 ° F (0° C to 45° C) at 10,000 Feet
-22° F to 176° F (-30° C to 80° C)
a. The Evolution X5 Satellite Router operates in this range when the ODU power consumption does not
exceed 80W. See Table 5 on page 12 for more detail.
b. The Evolution X5 Satellite Router operates in this range when the ODU power consumption does not
exceed 70W. See Table 5 on page 12 for more detail.
Temperature Gradient 1.0° C per 1min
Relative Humidity
Operational:
Storage:
0 to 90% non-condensing
5 to 93% non-condensing
Altitude
Operating:
Storage:
≤ 10,000 feet (3048m)
≤ 30,000 feet (9144m)
