12 iDirect Evolution X5 Satellite Router Installation and Safety Manual
RF Specifications
The Evolution X5 Satellite Router typical BUC/LNB power consumption is defined in Table 5.
Note: The typical power consumption ratings that follow are based on the coax
cables that are specified in the section on “Preparing the Coax Cables” on
page 22.
3.3 RF Specifications
The Evolution X5 Satellite Router RF specifications are presented in Table 6.
Table 5. Typical BUC/LNB Power Consumption
Cable
Length
Mode Typical Power Consumption (W): IDU, BUC, PLL/DRO LNB, Cable IFL
1W Ku 2W Ku 4W KU 2W C 5W C
NJT5034F NJT8301UF NJT5037F NJT8302UF NJT5017F NJT5207F NJT5667 NJT5669
50 ft.
RG-6
Normal 31 29 43 32 70 52 47 62
Sleep2018201821191922
250 ft.
RG-6
Normal 32 30 44 34 87
a
a. The Evolution X5 Satellite Router must be operating at less than 50°C when ODU power consumption
exceeds 70W. See Table 3 on page 10 for more detail.
57 51 69
Sleep2018201821201919
Table 6. RF Specifications
Category Description
Frequency Range
Transmit:
Receive:
950-1700 MHz
950-2150 MHz
Frequency Tuning Step Size
Transmit:
Receive:
38 Hz
Sub-Hertz with Demodulator
RF Power Range
Transmit:
Receive:
-35 dBm to +7 dBm
Single Carrier Input Power: -65 dBm to -15 dBm
Composite Wideband Input Power: -5 dBm (maximum)
RF Power Adjustability
Transmit:
Receive:
0.5 dB Nominal Step Size
Under AGC for all valid Rx input power range
