Power Specifications
3.2 Power Specifications
This section provides the AC power specifications and the typical BUC/LNB for the Evolution
X5 Satellite Router.
The Evolution X5 Satellite Router AC power specifications are defined in Table 4.
Table 4. AC Power Specifications
Category Description
Input Voltage Range 100 — 240 V~ (VAC) Single Phase
Frequency 50 Hz – 60 Hz
AC Power Consumption ≤ 4.0 Amps maximum
DC Power F-Connector BUC Power (IFL) +24 VDC, 70W (up to 50° C), 3.5 Amps maximum (up
to 5W BUCs are supported)
a
LNB Power (IFL) +19 VDC / +14 VDC 300mA (DiSEqC) 22 kHz DiSEqC
tone
a. See the footnotes to Table 3 on page 10 for further detail.
Protection • Internal, primary current fuse, inside power supply
• Over current protection
•Short protection
Power Factor Correction Complies with EN61000-3-2 and EN61000-3-3
Efficiency 87% typical (Energy Star Compliant)
Input Transient Response 0.5 msec for 50% load change typical
AC Input Connector IEC-320-C14
AC Power Cord 18 AWG, country dependent
Typical BUC
with LNB
Power at
90 VAC
Power at
254 VAC
2W Ku-Band 0.6 A 0.3 A
4W Ku-Band 0.70 A 0.30 A
2W C-Band 0.6 A 0.3 A
5W C-Band 1.0 A 0.4 A
