34 iDirect Evolution X5 Satellite Router Installation and Safety Manual
Front Panel LED Status Indicators
STATUS OFF The IDU is functioning properly.
FLASHING GREEN The unit is booting. DRAM test is in progress.
RED Indicates a serious fault or failure in the
software, hardware, or configuration. May
indicate that the DRAM test failed.
TX GREEN The IDU’s transmitter is active.
RX GREEN The IDU is locked to the downstream and it is
receiving data.
FLASHING GREEN The demodulator is locked to the downstream
but NCR is not locked. Data is not being
received by the modem.
Table 13. Front Panel LED Indicators (continued)
LED Label LED Color Indicated Unit Status
