1.17.2 Menu & submenu structure
Top-down diagram of the OCEAN SEVEN 310 menu structure.
1.17.3 Menu header structure
The menu and submenus show a list of commands preceded by two header lines, which identify the
menu or submenu and show the relevant information about the probe in square, round and glyph
brackets.
OCEAN SEVEN 310 - Id:0317003 {USR}[sw](1.0_10 05/17)Oct 01 14:19:51.61 2017
They are:
OCEAN SEVEN 310 Type of probe and name.
Id:0317003 Identification Code. This code corresponds to the serial number too.
{USR} Indicates the access rights to the probe functions and configuration. It
dynamically changes whenever the access rights command is carried
out and according to the entered password. The access rights acronyms
are: USR, SRV, ADM (see the dedicated description).
[sw] or [fw] Conductivity measuring range: sea water or fresh water.
(1.2_10 01/18) Probe firmware release number and firmware release date.
Main Menu
1 – Acquisition
2 – Memory
3 - Calibration
4 - Service
5 – Non-Verbose mode
Memory Management
1 – Memory status
2 – Show stored data
3 - Delete data
4 –initialize data memory
Service
1 – Configuration
2 – Diagnostic
3 - Raw Counts
4 - Raw mV
Diagnostics
1 – Test 16bit ADC
2 – Service Reading
3 – Serial interface
4 – Real time clock
5 - Time base
Configuration
1 – Data acquisition
2 – Operting parameters
3 – Acquired sensor parameters
4 – Change date&time
5 - External system
Data Acquisition
1 – Real time
2 – Pressure
3 – Timed
4 – Conditional
5 – Continuos
6 – Burst
