2 INSTALLATION AND START UP
Unpacking, installation and start-up procedures concerning the OCEAN SEVEN 310 are described in
the “Installation & Start-up” flayer supplied with each probe.
2.1 SHIPPING LIST
Description Quantity
A. OCEAN SEVEN 310 probe 1
B. Telemetry Deck Unit 1
C. Cable for probe connection to a PC via RS232C 1 x 3 m
D. Cable simulator to connect the probe to the Telemetry Deck Unit 1 x 3 m
E. Cable to connect the Telemetry Deck Unit to a PC 1 x 3 m
F. Cable to power the Telemetry Deck Unit 1
G. Dummy cap for probe bulkhead connector/s 1 x connector
H. Sensor maintenance kit, including:
❖ Conductivity sensor cleaning solution 1x 25 ml
❖ Spare membrane cap for oxygen sensor 1
❖ Oxygen maintenance kit 1
❖ Oxygen electrolyte 2 x 25 ml
❖ pH calibration cup 1
❖ Spare pH sensor hydrating cap 1
❖ Spare reference sensor hydrating cap 1
❖ pH buffer solution - pH 7 1x100 ml
❖ pH buffer solution - pH 4 1x100 ml
❖ pH reference sensor storage solution 2 x 25 ml
❖ pH sensor etching solution 1x 3 ml
I. USB data storage key with software and documentation 1
J. Internal rechargeable battery pack and international charger 1
K. “AA” Battery holder 1x3 AA; 1x1 AA
Note
➢ Items B,D,E,F are present only when the purchase order includes the telemetry optional interfaces.
➢ Item B includes the battery charger, if it is a Portable Deck Unit.
➢ Sensor maintenance kit contents (item H) depends on the probe sensor suite.
➢ Customized submersible cables can be included in the shipping list if external sensors are interfaced with the
OCEAN SEVEN 310 probe
➢ Item J is present only if the optional battery pack is ordered.
2.1.1 Laboratory RS232C cable
A laboratory RS232C cable is provided to interface the probe to a personal computer: its 6-pin female
underwater connector fits the 6-pin male connector of the probe; its 9-pin female connector (Cannon
DB9) fits a standard AT type RS232C serial interface. Wiring of the cable can be found in the documents
enclosed to the Operator’s Manual and describing the bulkhead connectors and cables completing the
probe package. The laboratory RS232C cable comes complete with a probe international power supply
AC/DC converter.
2.2 INSTALLATION
Unpack and inspect the shipped parts; check the materials of the above shipping list and be sure that
no damage has occurred during transport.
2.2.1 Internal and external battery packs
The probe is shipped without batteries installed. Therefore, if needed, install the battery. A detailed
description can be found in Appendix “A” and on the OS310 flyer. In case the high-voltage telemetry is
installed, the internal battery must not be present or installable. In this case it is mandatory to use
external submersible battery pack for unattended self-recording operations.
